(888) 312-8812 Login SignupBENDIX 065647 Air Dryer
Tap to view 6 more
$1,22949
Limited availability at this price!
In Stock
Get as soon as Monday, Oct 26
BENDIX 065647 Part Description
Manufacturer
Product Description
Air Dryer
Features & Benefits
- Complete dryer assembly cures moisture that a cartridge alone cannot
- Buses and tankers put the heaviest load on an air dryer
- Installs as a complete assembly ready to mount and plumb
- Moisture-free output helps stop winter freeze-ups in lines and valves
Bendix Air Brake Dryer
The Bendix Air Brake Dryer is a complete dryer assembly that removes moisture and oil from the compressor's air before it reaches the brakes. As a full unit, the Bendix 065647 fixes a stuck purge valve or failed heater that a new cartridge cannot. Water in the tanks after a cartridge change is the usual sign the dryer body itself has failed. Draining every tank after installation clears moisture left by the old unit.
BENDIX 065647 Specifications
Product Attributes
| Air Dryer Type | Stand-Alone |
| Body Mounting | A~ .425 Hole with 3/8-24 UNF-2A Bolted Joint (8x) |
| Cartridge Stabilizer Ring Included | No |
| Cartridge Thread | 5/8-11 UNC-2A |
| Cartridge Type | Standard |
| Cautionary Note(s) | Drop-In (DI) version - do not replace with standard dryer. |
| Clamp Band Angle (CW from SUP) | Not applicable to this part |
| Clearance to Remove Cartridge | 11.00 IN |
| Control Port | 1/4-18 NPT |
| Cut-In Pressure | Not applicable to this part |
| Cut-Out Pressure | Not applicable to this part |
| Delivery Port 1 | 1/2-14 NPT |
| Delivery Port 2 | Not applicable to this part |
| Extended Purge Port | Not applicable to this part |
| Governor Included | No |
| Governor Mounting Bracket | Not applicable to this part |
| Governor Mounting Bracket Angle (CCW from SUP) | Not applicable to this part |
| Governor Type | Not applicable to this part |
| Heater / Thermostat Rating | 12V / 75W |
| Heater Connector Color | White |
| Heater Connector Type | Metri-Pack 280 Series 2-Way Sealed Connector (Male) |
| Lower Mounting Bracket | .41 IN x 1.15 IN Slot (2x) |
| Lower Mounting Bracket Angle (CCW from SUP) | Loose in Box |
| Market Indicator | Aftermarket New |
| Maximum Inlet Temperature | 160 AdegF (71 AdegC) |
| Minimum Operating Temperature | -40 AdegF (-40 AdegC) |
| Purge Exhaust Port | Open (No Cover) |
| Purge Valve Type | Soft Seat |
| Purge Volume | Standard |
| Remote Fill Feature | 1/8-27 NPT (Makeup Line Kit) |
| Remote Purge Port | Not applicable to this part |
| Safety Valve Opening Pressure | 200 PSI |
| Supply Port | 1/2-14 NPT |
| Turbo Cut-off Function | Not applicable to this part |
| Upper Mounting Bracket | .41 IN x 1.15 IN Slot (2x) |
| Upper Mounting Bracket Angle (CCW from SUP) | Loose in Box |
| Upper Mounting Bracket Height (from Lower Mounting Bracket) | Loose in Box |
| Upper Mounting Type | Strap (Carbon Steel) |
Additional Information
| Country of Origin (Primary) | MX |
| UPC | 04068078353295 |
| VMRS Code | 013010252 |
BENDIX 065647 Cross References
| Brand | Part Number |
|---|---|
| BW065647 | |
| N/A | 107695 |
