(888) 312-8812 Login SignupLETRIKA MS384 Starter 12V, 10T, CCW, Letrika/MAHLE AZE26, 2kW
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
LETRIKA MS384 Part Description
Manufacturer
Technical Data
| Product | Starter |
| Letrika P/N | IS1042 |
| Voltage | 12 V |
| Power | 2.0 kW |
| OEM P/N | 11.131.056 |
| MAHLE P/N | MS 384 |
| Description | AZE2625 |
| No. of pinion teeth | 10 |
| Module | 2.116 mm |
| Distance over two teeth | 10.48 mm |
| Outside diameter of pinion | 27.91 mm |
| Notes | Anti-clockwise rotation |
| Noseless version of starter | |
| With reduction gear |
| Letrika P/N | OEM P/N | MAHLE P/N | |
|---|---|---|---|
| IS1042 | 11.131.056 AZE2625 12V 2,0kW | MS 384 | Available |
Related Parts
| Letrika P/N | MAHLE P/N | DESCRIPTION | POS |
|---|---|---|---|
| 16.282.165 | MSX 1256 | Stator | 12 |
| 16.908.349 | MSX 1330 | Set of brushes | 14 |
| 16.902.501 | MSX 1579 | Gear with clutch | 18 |
| 16.908.353 | MSX 193 | Fixing set | 11 |
| 16.908.351 | MSX 216 | Bearing | 10 |
| 16.908.386 | MSX 262 | Brush holder | 13 |
| 16.908.519 | MSX 313 | Rear-end bracket | 15 |
| 16.908.347 | MSX 36 | Lever | 7 |
| 16.906.831 | MSX 402 | Switch | 4 |
| 16.283.460 | MSX 526 | Drive end bracket | 1 |
| 16.908.389 | MSX 720 | Reduction gear | 8 |
| 16.361.412 | MSX 772 | Armature | 9 |
| 16.908.830 | MSX 88 | Pinion with clutch | 6 |
LETRIKA MS384 Cross References
| Brand | Part Number |
|---|---|
| IS1042, MS 384 | |
| BOSCH | 0001110061, 0001110062, 0001124005, 0001124006, 0001125001, 0001125002, 0001125031, 0986016190, 0986016990, SR 0404 X, SR 0414 X |
| HELLA | 8EA 726 222-001, 8EA 732 656-001, CS 598, CS 801 |
| LESTER | 17231, 17234, 17750 |
| LUCAS | LRS00964, LRT00133 |
| MAGNETI MARELLI | 9432 512 25, 9432 512 28, MSR 658, MSR 766 |
| VALEO | 455 628, 458 041, D 7 R 131, D 7 RS 31 |
| VW (VOLKSWAGEN) | 02B 911 023 A, 02B 911 023 AX, 02B 911 023 B, 02B 911 023 C, 02B 911 023 CX, 02B 911 023 D, 02B 911 023 DX, 02B 911 023 J |
