Horton 9904088 - VS Directly Controlled Fan Drive
$1,57399
MSRP: $1,960.27
Save: $386.28
Limited Availability
Pay over 3-12 months with
. Learn more
. Learn more
HORTON part description
Product Description
VS Directly Controlled Fan Drive
Application Summary
FREIGHTLINER
Features & Benefits
- Rapid response to changing cooling requirements
- Enhanced fuel economy, lower noise and maximum efficiency
- Compatible with Horton and other fan manufacturer parts
- Simple, flexible design for easier installation
Fan clutch, drive, engine cooling system, fully variable, performance, horsepower, viscous
Product Attributes
| CLUTCH TO FAN MOUNTING SURFACE | 4.59 IN |
| Connector Type | Delphi Metri-Pack Series 150 |
| Fan Bolt Circle | 6 IN |
| FAN PILOT DIAMETER | 5 IN |
| Heavy Duty | FALSE |
| LENGTH OF WIRE | 9.84 IN |
| MOUNTING BOLT CIRCLE | 2.36 IN |
| MOUNTING PILOT DIAMETER | 1 IN |
| MOUNTING THREAD TYPE / SLOTS | M30X2-6G-LH |
| OUTER (OVERALL) DIAMETER | 9.17 IN |
| Overall Length | 6.82 IN |
| Voltage | 12V |
Additional Information
| Country of Origin (Primary) | DE |
| Harmonized Tariff Code (Schedule B) | 8505200000 |
| Harmonized Tariff Code (HTS) | 8505200000 |
| OEM's Part Number | 9804088 |
| Warranty Distance | 100000 |
| Warranty Distance UOM | DH |
| Warranty Special | 2500 Hours |
| Warranty Special UOM | TX |
| Warranty Time | 12 |
| Warranty Time UOM | MO |
| VMRS Code | 042003036 |
HORTON 9904088 Cross Reference
We have 2 alternatives for the 9904088 by HORTON:
