RAYBESTOS 980933R Raybestos R-Line Brake Rotor

★★★★★ (0)

$61.31

MSRP Pricing shown.

Out of Stock

We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.

We may have similar parts for sale. Search Alternatives >

RAYBESTOS 980933R Part Description

Manufacturer

RAYBESTOS

Product Description

Raybestos R-Line Brake Rotor

Application Summary

2014-2009 Mitsubishi Lancer Front

Features & Benefits

  • OE Fit, Form, and Function
  • Developed from OE samples and made with G3000-qualified material, ensuring OE fit, form and function for dependable braking.
  • SAE Standard
  • R-Line Rotors meet the SAE standard for tensile strength, providing structural integrity and a maximum service life.
  • Low Initial Lateral Runout and Thickness Variation
  • R-Line Rotors have a small parameter lateral runout and a thickness variation ensuring less pedal pulsation, less brake noise, and an extended pad life.
  • Mill Balanced Edges
  • R-Line Rotors are mill balanced and 100 percent validated. This helps minimize the thickness variation on the rotor and leads to minimized vibration and smoother stopping.

RAYBESTOS 980933R Specifications

Product Attributes

ABS Tone Ring IncludedNo
Center Hole Diameter2.717 IN
Center Hole Diameter69 MM
Conventional Or Drum-In-Hat Type RotorConventional
Discard Thickness0.882 IN
Discard Thickness22.4 MM
Harmonize Code8708.30.5030
Inside Diameter7.52 IN
Inside Diameter191 MM
Mounting Bolt Hole Circle Diameter4.5 IN
Mounting Bolt Hole Circle Diameter114.3 MM
Mounting Bolt Hole Diameter0.495 IN
Mounting Bolt Hole Diameter12.55 MM
Mounting Bolt Hole Quantity5
Nominal Thickness0.945 IN
Nominal Thickness24 MM
Outside Diameter11.575 IN
Outside Diameter294 MM
Overall Height1.805 IN
Overall Height45.85 MM
Salability RestrictionsNo
Solid Or Vented Type RotorVented
Stud/Lug Hole Quantity5
Surface TypeSmooth
UNSPSC Code25171715

Additional Information

Country of Origin (Primary)CN
Canadian Harmonizing Tariff Code8708309990
Harmonized Tariff Code (HTS)8708305030
UPC00829352975961

RAYBESTOS 980933R Cross References

BrandPart Number
ADVANCE AUTO PARTSYH291438P
AUTOZONE77502, 77502DG
Advance Auto PartsYH291438
BENDIXPRT6068
BRAKEBEST980933FZN, 980933R, 980933RGS
CENTRIC120.46078, 121.46078, 126.46078CSL, 126.46078CSR, 126.46078SL, 126.46078SR, 127.46078L, 127.46078R, 128.46078L, 128.46078R
Centric Parts120.46078, 121.46078, 126.46078CSL, 126.46078CSR, 126.46078SL, 126.46078SR, 127.46078L, 127.46078R, 128.46078L, 128.46078R
DURA CORPBR901000
DuraGoBR901000
Dynamic Friction Company604-72044
MAGMA PRODUCTSPMR403019
MITSUBISHI4615A113
Mitsubishi4615A189
NEWTEK AUTOMOTIVE31594
Newtek Automotive USA31594
Qualis44717
UAPR46078
WAGNER BRAKEBD180414
WORLDPAC1407-291438

RAYBESTOS 980933R Fits Vehicles

  • Mitsubishi Lancer (2009-2015)
  • Mitsubishi Outlander PHEV (2018-2022)

RAYBESTOS 980933R Customer Reviews

No reviews yet

Be the first to review this product!

Write a Review

Raybestos 980933R Disc Brake Rotor Raybestos R-Line Brake Rotor
