RAYBESTOS 980975 Part Description
Manufacturer
Product Description
Raybestos Specialty - Truck Coated Brake Rotor
Application Summary
2021-2012 Nissan NV2500 Front, 2021-2012 Nissan NV3500 Front, 2021-2012 Nissan NV1500 Front
Features & Benefits
- OE Fit, Form, and Function
- Our vehicle-specific design matches OE fit, form and function, providing ultimate strength and performance
- Cooling Vanes
- We dedicate time to match the cooling vanes on our Specialty rotors to OE designs, ensuring: Optimal cooling Reduced fade Less noise Increased pad life
- Coating
- All Specialty rotors are protected against the elements. All new Specialty rotors come fully coated with Grey Fusion 4.0® rated at 300 hrs. salt spray or a Black Fusion painted hat and edge for rust protection.
- All Specialty rotors are protected against the elements. All new Specialty rotors come fully coated with Grey Fusion 4.0(R) rated at 300 hrs. salt spray or a Black Fusion painted hat and edge for rust protection.
- SAE Standard for Tensile Strength
- Our rotors follow SAE standards for tensile strength, hardness, and iron grade, providing structural integrity and maximum service life
- Turned Finish
- A turned finish provides an excellent surface for the pads to engage with to ensure a smooth and effective stop right out of the box
RAYBESTOS 980975 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 4.84 IN |
| Center Hole Diameter | 122.95 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Discard Thickness | 1.437 IN |
| Discard Thickness | 36.5 MM |
| Harmonize Code | 8708.30.5030 |
| Inside Diameter | 10.043 IN |
| Inside Diameter | 255.1 MM |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 6.5 IN |
| Mounting Bolt Hole Circle Diameter | 165.1 MM |
| Mounting Bolt Hole Diameter | 0.573 IN |
| Mounting Bolt Hole Diameter | 14.55 MM |
| Mounting Bolt Hole Quantity | 8 |
| Nominal Thickness | 1.496 IN |
| Nominal Thickness | 38 MM |
| Outside Diameter | 14.161 IN |
| Outside Diameter | 359.7 MM |
| Overall Height | 3.78 IN |
| Overall Height | 96 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 8 |
| Surface Type | Smooth |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00887213015089 |
RAYBESTOS 980975 Cross References
| Brand | Part Number |
|---|---|
| ADVANCE AUTO PARTS | YH335275, YH335275P |
| AUTOXTRA | AX901108 |
| AUTOZONE | 60119, 60119DG |
| AutoZone | 60119DL |
| BENDIX | PRT6196 |
| BRAKEBEST | 980975, 980975FZN, 980975R, 980975RGS |
| CENTRIC | 120.42110, 121.42110, 126.42110SL, 126.42110SR, 127.42110L, 127.42110R, 128.42110L, 128.42110R, 320.42110, 120.4211 |
| Centric Parts | 120.42110, 121.42110, 126.42110SL, 126.42110SR, 127.42110L, 127.42110R, 128.42110L, 128.42110R, 320.42110 |
| DATSUN/NISSAN | 402061PA1A, 402061PA1B |
| DURA CORP | BR5659, BR901108 |
| DuraGo | BR901108, BR901108-02 |
| Dynamic Friction Company | 600-67102 |
| MAGMA PRODUCTS | PSR425119 |
| NEOTEK | 1061112GF |
| NEWTEK AUTOMOTIVE | 5659, R1108 |
| Newtek Automotive USA | 5659, R1108 |
| Nissan | 402061PA1A, 402061PA1B |
| POWERSTOP | JBR1573EVC |
| PROMAX | 14-5659 |
| Qualis | 44752 |
| TopNotch | TN980975GEO |
| UAP | R42110 |
| WAGNER BRAKE | BD180484 |
| WORLDPAC | 1407-335275, 1427-523966 |
| Winhere | 6621319 |
RAYBESTOS 980975 Fits Vehicles
- Nissan NV3500 (2012-2021)
- Nissan NV2500 (2012-2021)
- Nissan NV1500 (2012-2021)
