Centric 123.40015 - C-Tek Standard Brake Drum
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
Sometimes we may have similar parts for sale, click the button below to see if anything matches.
CENTRIC part description
Product Description
C-Tek Standard Brake Drum
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
Product Attributes
| Weight [cntrc] Kgs | 2.273 |
| Weight [cntrc] Lbs | 5.000 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 100.000 |
| Bolt Circle Diameter [cntrc] In | 3.937 |
| Hub Hole / Register [cntrc] Mm | 60.900 |
| Hub Hole / Register [cntrc] In | 2.398 |
| Height [cntrc] Mm | 62.000 |
| Height [cntrc] In | 2.441 |
| Friction Surface Width [cntrc] Mm | 38.700 |
| Friction Surface Width [cntrc] In | 1.524 |
| Product Grade [cntrc] | Standard |
| Maximum Brake Diameter (Discard) | 181.000 MM |
| Maximum Brake Diameter (Discard) | 7.126 IN |
| Bolt Hole Quantity | 4 |
| Outside Diameter | 226.000 MM |
| Outside Diameter | 8.898 IN |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 12.400 MM |
| Mounting Hole Diameter | 0.488 IN |
| Nominal Drum Diameter | 179.300 MM |
| Nominal Drum Diameter | 7.059 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 889590000030 |
Part Interchanges
Fits Vehicles
- Honda Insight (2000-2006)
