ACDelco FW430 - Front Wheel Hub and Bearing Assembly with Wheel Studs
$4349
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
ACDELCO part description
Product Description
Front Wheel Hub and Bearing
Product Attributes
| Flange Included | Yes |
| Anti Lock Braking System | No |
| Flange Offset | 1.656 IN |
| Hub Pilot Diameter | 66.84 IN |
| Flange Bolt Hole Quantity | 3 |
| Anti-Lock Brake Sensor Included | No |
| Brake Pilot Diameter | 2.65 IN |
| Flange Bolts Included | No |
| Wheel Stud Quantity | 5 |
| Outside Diameter | 157 MM |
| Flange Shape | Triangle |
| Wheel Stud Size (mm) | 14 mm |
| Flange Offset | 42.06 MM |
| Mounting Hardware Included | No |
| Brake Pilot Diameter | 67.33 MM |
| Hub Pilot Diameter | 2.63 MM |
| Flange Diameter | 6.18 IN |
| Flange Diameter | 157 MM |
| Product Description | ACDelco GM Original Equipment Wheel Bearing and Hub Assembly supports the vehicle while allowing the wheel to rotate, and are GM-recommended replacements for your vehicle's original components. This original equipment wheel bearing and hub assembly has been manufactured to fit your GM vehicle, providing the same performance, durability, and service life you expect from General Motors. ⚠<b> WARNING:</b> Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| FAQ - Question 1 | Are there specifications I should check to see how tight the center hub bearing attachment nut should be? |
| FAQ - Question 3 | Can I use a replacement hub assembly that comes with an ABS cable when my vehicle does not have ABS? |
| Anti Lock Braking System Type | Encoder |
| Signs of Wear & Troubleshooting - Section 1 - Bullet 3 | Excessive play at tire and wheel |
| Good Maintenance Practices - Section 1 - Bullet 2 | Follow the manufacturers recommended torque specification. |
| Features & Benefits - Bullet 4 | GM OE bearing designs are dimensionally optimized to work with their mating parts |
| Features & Benefits - Bullet 3 | GM OE parts are built to help withstand potholes and designed to maximize seal life |
| Features & Benefits - Bullet 5 | GM-recommended replacement part for your GM vehicle's original factory component |
| Signs of Wear & Troubleshooting - Section 1 - Bullet 1 | Grinding or humming noise from hub assembly maybe more noticeable while turning |
| FAQ - Question 2 | Is it normal for the bearing to have back-and-forth movement inside the hub assembly? |
| Good Maintenance Practices - Section 1 - Bullet 1 | Keep wheel lug nuts at proper torque and do not overtighten center hub bearing to constant velocity shaft nut. |
| Features & Benefits - Bullet 7 | Manufactured to GM OE specification for fit, form, and function |
| Features & Benefits - Bullet 2 | Maximum lateral stiffness for optimum ride, handling, and driving dynamics |
| Wheel Pilot Diameter | 66.84 MM |
| Programming Required | No |
| Features & Benefits - Bullet 6 | Offering the quality, reliability, and durability of GM OE |
| Signs of Wear & Troubleshooting - Section 1 - Header | Signs of wear for wheel bearing and hub assemblies include but are not limited to: |
| Features & Benefits - Bullet 1 | Supports the vehicle while allowing the wheel to rotate |
| Signs of Wear & Troubleshooting - Section 1 - Bullet 2 | Tire and wheel vibration |
| Wheel Pilot Diameter | 2.63 IN |
| Signs of Wear & Troubleshooting - Section 1 - Bullet 4 | Wheel hot to the touch |
| Meets or Exceeds Original Equipment Manufacture Specifications | Yes |
| Wheel Stud Size (in) | 0.55 in |
| Wheel Studs Included | Yes |
| FAQ - Answer 3 | Yes, in some cases replacement hub assemblies come with ABS cables because most vehicles are now equipped with ABS. For non-ABS vehicles the cable can be cut off before hub installation. |
| FAQ - Answer 2 | Yes. It is normal for the bearing to have some movement inside the hub assembly; this movement is controlled to a specification. |
| FAQ - Answer 1 | Yes. The nut should be torqued to the specifications found in the vehicle's service manual. |
| Bolt Circle Diameter | 4.57 IN |
| Outside Diameter | 6.18 IN |
| Flange Bolt Hole Diameter | 12 MM |
| Flange Bolt Hole Diameter | 0.47 IN |
| Bolt Circle Diameter | 116 MM |
Additional Information
| Warranty Special | 24 Months/Unlimited Miles Limited Warranty (Parts Only). Please see ACDelco.com for more details|36 Months/60,000 Kilometers Limited Warranty (Parts Only). Please see ACDelcocanada.com for more details |
| Harmonized Tariff Code (HTS) | 8708995800 |
| Country of Origin (Primary) | US |
| Warranty Special UOM | TX |
| UPC | 00808709292869 |
Fits Vehicles
- Chevrolet Camaro (2014-2015)
