Peterson Lighting 1218A-9 - LED Turn Signal, Round, Ece, AMP, Flange-Mount 4", Multi-volt, amber, poly bag
- Part Number
- 1218A-9
- Manufacturer
- PETERSON LIGHTING
- Description
-
LED Turn Signal, Round, Ece, AMP, Flange-Mount 4", Multi-volt, amber, poly bag
details
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
Sometimes we may have similar parts for sale, click the button below to see if anything matches.
PETERSON LIGHTING part description
1217A-9/1218A-9 LumenX® 4" Round LED Turn Signal
Features & Benefits
- 9-Diode
- AMP-compatible connector integrated into housing
- 9-32 volt operating range is compatible with both 12V & 24V systems
- Kit includes light and 817-49 plug. 1217KA-9 also includes grommet
- Sealed lens and housing meets IP67 ingress level
- Grommet version fits 114mm hole in material up to 6mm
- Also fits the 417 and 426 surface-mount pods & brackets
- For Export Only
Product Description
LED TURN SIGNAL, ROUND, ECE, AMP, FLANGE-MOUNT 4", MV
Features & Benefits
- 9 diodes.
- AMP-compatible connector integrated into housing.
- Assembled in USA.
- ECE complaint.
- Grommet version fits 114 mm hole in material up to 6 mm.
- Kits include light and plug. 1217KA-9 also includes grommet.
- Lumenx® lens and circuitry.
- Multi-volt design is compatible with both 12 and 24 volt systems.
- Multivolt version available.
- Regulated design provides voltage protection and consistent output.
- Sealed lens and housing meets IP67 ingress level.
- See Peterson Master Catalog pages 184–185 & 187 for mounting options.
- Voltage Regulated.
- White diodes and advanced optics fully illuminate red lens.
hardshell plug - mfg. pack - B417-48 - std qty 100
Product Attributes
| Bulb Technology | LED |
| Bulb/diode Count | 9 |
| California Prop65 Required | Y |
| Container Type | poly bag |
| Diameter | 5.5 IN |
| Ground Type | wire |
| Height | 5.5 in |
| Integral Reflex | N |
| Length | 5.5 IN |
| Lens Color | amber |
| Light Color | amber |
| Maximum Voltage | 32 Volts |
| Minimum Voltage | 9 Volts |
| Mounting Type | flange |
| Multi-volt | Y |
| Regulatory Compliance | ECE |
| Shape | round |
| Termination | AMP |
| Voltage | 12V / 24V |
| Width | 1.49 in |
Additional Information
| Warranty Special | LIMITED LIFETIME WARRANTY See full warranty terms: https://pmlights.com/warranty |
| Warranty Special UOM | TX |
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 8512204000 |
| UPC | 00044464998992 |
| VMRS Code | 034003194 |
Peterson Lighting® is a family-owned company that produces and distributes vehicle safety lighting systems mirrors, and other related safety products and accessories. It has been in the business for 75 years, and currently, it offers over 2,200 products designed for various applications, including tilt-bed and cargo vehicles and light- and medium-duty trailers. Peterson Lighting believes that full commitment to quality is its responsibility as a market leader. All its components are designed and manufactured only in its ISO 9001/QS-9000-certified facility in Grandview, MO. This facility is handled by knowledgeable and highly skilled specialists, who are as dedicated and passionate as the company when it comes to quality.
