HELLA 002768082 - Disc Type Low-Tone, 12 V, 335 Hz with Bracket
$3449
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
HELLA part description
Product Description
Disc Type Low-Tone, 12 V, 335 Hz with Bracket
Features & Benefits
- With moisture protection
Product Attributes
| Frequency Range [hz] | 335 |
| Depth [mm] | 53 |
| Overall Height [mm] | 129 |
| Voltage [V] | 12 |
| Diameter [mm] | 112 |
| Power Consumption [w] | 72 |
| Temperature Range To [°c] | 60 |
| Supplementary Article/Info 2 | with E quality seal |
| Housing Colour | Grey |
| Protection Type (IP Code) | X9K |
| Temperature Range From [°c] | -40 |
| Test Mark | ECE |
| Assy./disassy. By Qualified Personnel Required! | . |
| Sound Level [dB(A)] | 116 |
| Signal | Low Tone |
| Mounting Type | Flat Plug-in Connector |
| Measurements [cm] | 5.3 x 12.9 |
| Homologation | ECE-R28 |
| Diameter [in] | 4.40 |
| Frequency Range From [hz] | 335 |
| Includes | (1) Universal Mounting Bracket |
| Protection | IP54 |
| Bracket | M10 mounting screw |
| Diameter [cm] | 11.2 |
| Single Includes | (1) Low-Tone Disc Horn, Mounting Brackets, Step-by-Step Mounting Instructions |
Additional Information
| Warranty Time UOM | MO |
| Warranty Time | 12 |
| Country of Origin (Primary) | IN |
| Harmonized Tariff Code (HTS) | 8512300020 |
| UPC | 04082300052626 |
Part Interchanges
HELLA 002768082 Cross Reference
We have 2 alternatives for the 002768082 by HELLA:
