(888) 312-8812 Login SignupMELLING ENGINE PRODUCTS M-86E M-86E Stock Replacement : Standard Volume, Standard Pressure, Cast Iron Oil Pump With Gasket
Tap to view 1 more
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
MELLING ENGINE PRODUCTS M-86E Part Description
Manufacturer
Product Description
Stock Replacement Oil Pump
Features & Benefits
- Precision engineered for optimum fit and function
- Manufactured from high quality materials for consistent durable wear
- Designed for long-life and worry-free performance
- Meets or exceeds original equipment specifications
MELLING ENGINE PRODUCTS M-86E Specifications
Product Attributes
| Title | Engine Oil Pump |
| Width | 4.87 IN |
| Width | 124.0 MM |
| Height | 2.86 IN |
| Height | 73.0 MM |
| Grade Type | Standard Replacement |
| Gasket Or Seal Included | Yes |
| Mounting Hole Quantity | 2 |
| Housing Material | Cast Iron |
| Drive Type | Drive Shaft |
| Oil Pump Type | Gear |
| Pickup Screen Diameter | 0.68 IN |
| Pickup Screen Diameter | 17.0 MM |
| Mounting Hole Diameter | 0.375 IN |
| Mounting Hole Diameter | 10.0 MM |
| Oil Pump Pressure Type | Standard Pressure |
| Oil Pump Volume Type | Standard Volume |
| Finish | Rust Preventative |
| Pickup Tube Diameter | 0.550 IN |
| Pickup Tube Diameter | 14.00 MM |
| Gear Material | Steel |
| Adjustable Bypass Pressure | No |
| Alternate Pressure Springs Included | No |
| Drive Shaft Included | No |
| Pickup Screen Included | No |
| Intermediate Shaft Included | No |
| Inlet Size (in) | 0.550 |
| Inlet Size (mm) | 14.00 |
| Cover Material | Cast Iron |
| Bolts Included | No |
| Bushing Included | No |
| Cotter Pin Included | No |
| Governor Spinner Included | No |
| Guide Included | No |
| Nylon Bushing Included | No |
| O-Ring Included | No |
| Pump Cover Included | Yes |
| Shaft Material | Not Applicable |
| Timing Cover Included | No |
| Washers Included | No |
| Spacer Included | No |
| Gears Included | Yes |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (HTS) | 8413309060 |
| Harmonized Tariff Code (Schedule B) | 8413309000 |
| Warranty Time UOM | MO |
| Warranty Time | 12 |
| UPC | 00729295101604 |
MELLING ENGINE PRODUCTS M-86E Cross References
| Brand | Part Number |
|---|---|
| Avon Automotive | A-86E |
| Badger | 41-160HPU, B-86E |
| Balkamp | 601-1640 |
| Dynagear | DM-86E |
| Elgin | EM-86E |
| Enginetech | EP86E |
| Federated | DM-86E |
| Fleet-Tuf | OP288 |
| Ford | D9ZZ-6600-A |
| Hoof | HM86E |
| ITM Engine Components | 057-1073, 057-1076, N/A |
| MAHLE | 601-8032 |
| MELLING ENGINE PRODUCTS | M-86E |
| Melling | M-86E |
| N/A | N/A |
| Perfect Circle | 601-8032, P86E |
| Pioneer | OP-86-E |
| Safety Auto Parts Corp | N/A |
| Sealed Power | 224-43405 |
| TRW | 50198 |
| Topline | N/A |
| Wolverine/Blue Racer | OP-554 |
MELLING ENGINE PRODUCTS M-86E Fits Vehicles
- Ford Mustang (1979-1986, 1989-1990)
- Ford Thunderbird (1983-1988)
- Mercury Capri (1979)
- Mercury Cougar (1984-1986)
