(888) 312-8812 Login SignupDELPHI ES20200 Oxygen Sensor
$6399
Limited availability at this price!
1 Day Lead Time
Get it by Thursday, Aug 27
DELPHI ES20200 Part Description
Manufacturer
Product Description
Oxygen Sensor
Features & Benefits
- Delphi planar technology covers older, conical design sensors
- Smart design consolidates SKUs without using long wires
- Patented protective sensor coating helps prevent contamination
- Validated for all fuel types, including ethanol blends like E85
- OE tested to 150,000 miles, plus 2,000 hours severe thermal testing
- Delphi is a global OE manufacturer for oxygen sensor and all oxygen sensors are built to Delphi's OE standards
DELPHI ES20200 Specifications
Product Attributes
| Position(s) | Front, Front Right. For the position specific to your vehicle, refer to the Applications. |
| Package Contents | Oxygen Sensor, Instruction Sheet |
| Wiring Harness Length | 18.7 IN |
| Wiring Harness Length | 475.0 MM |
| Sensor Type | Narrow-Band |
| Terminal Type | Blade |
| Universal Or Specific Fit | Specific |
| Band Type | Narrow |
| Wire Quantity | 4 |
| Grade Type | Standard Replacement |
| Connector Shape | Square |
| Terminal Quantity | 4 |
| Connector Gender | Female |
| Terminal Gender | Female |
| Thread Diameter | 0.7 IN |
| Wrench Size | 22mm |
| Thread Size | M18 - 1.5 |
| Overall Length | 19.9 IN |
| Overall Length | 505.0 MM |
| Mounting Type | Threaded |
| Thread Diameter | 18.0 MM |
| Wire Gauge Measurement | 20.0 GU |
| Thread Type Standard | Metric |
| Heated | Yes |
Additional Information
| Warranty Distance UOM | DH |
| Warranty Distance | 12000 |
| Harmonized Tariff Code (Schedule B) | 9027100000 |
| Warranty Time UOM | MO |
| Warranty Time | 12 |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 9027102000 |
| UPC | 00689604147757 |
| VMRS Code | 045021011 |
| UNSPSC | 41111924 |
DELPHI ES20200 Cross References
| Brand | Part Number |
|---|---|
| ACDelco | 2131536 |
| BorgWarner | OS1469, OS2419 |
| Bosch | 13719, 15825 |
| Chrysler | 5602 9334AA, 5604 1941AA, 5604 4581AA |
| DENSO | 234-4653 |
| DENSO Auto Parts | 234-4653 |
| Kem | 138-643 |
| N/A | 25024257, 2344653, 138643, 56029334AA, 56041941AA, 56044581AA, 250-24276 |
| NTK | 23532 |
| Oextra | REA1487, REA1886 |
| SPECTRA PREMIUM | OS5256 |
| Standard Motor Products | SG1586, SG716, SG1851 |
| Walker Products | 250-24257 |
| Wells | SU3276, SU3322 |
DELPHI ES20200 Fits Vehicles
- Jeep Grand Cherokee (2001-2004)
- Dodge Ram 1500 (2002)
