(888) 312-8812 Login SignupDELPHI ES20169 Oxygen Sensor
$17799
Limited availability at this price!
5 Day Lead Time
Get it by Wednesday, Jul 8
DELPHI ES20169 Part Description
Manufacturer
Product Description
Oxygen Sensor
Features & Benefits
- Delphi planar technology covers older, conical design sensors
- Smart design consolidates SKUs without using long wires
- Patented protective sensor coating helps prevent contamination
- Validated for all fuel types, including ethanol blends like E85
- OE tested to 150,000 miles, plus 2,000 hours severe thermal testing
- Delphi is a global OE manufacturer for oxygen sensor and all oxygen sensors are built to Delphi's OE standards
DELPHI ES20169 Specifications
Product Attributes
| Position(s) | Rear, Rear Left, Rear Right. For the position specific to your vehicle, refer to the Applications. |
| Package Contents | Oxygen Sensor, Instruction Sheet |
| Wiring Harness Length | 37.6 IN |
| Wiring Harness Length | 955.0 MM |
| Sensor Type | Narrow-Band |
| Terminal Type | Blade |
| Universal Or Specific Fit | Specific |
| Band Type | Narrow |
| Wire Quantity | 4 |
| Grade Type | Standard Replacement |
| Connector Shape | Oblong with Flat |
| Terminal Quantity | 4 |
| Connector Gender | Male |
| Terminal Gender | Male |
| Thread Diameter | 0.7 IN |
| Wrench Size | 22mm |
| Thread Size | M18 - 1.5 |
| Overall Length | 38.8 IN |
| Overall Length | 985.0 MM |
| Mounting Type | Threaded |
| Thread Diameter | 18.0 MM |
| Wire Gauge Measurement | 20.0 GU |
| Thread Type Standard | Metric |
| Heated | Yes |
Additional Information
| Warranty Distance UOM | DH |
| Warranty Distance | 12000 |
| Harmonized Tariff Code (Schedule B) | 9027100000 |
| Warranty Time UOM | MO |
| Warranty Time | 12 |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 9027102000 |
| UPC | 00689604147504 |
| VMRS Code | 045021011 |
| UNSPSC | 41111924 |
DELPHI ES20169 Cross References
| Brand | Part Number |
|---|---|
| Audi | 022 906 265 B, 1K0 998 262 B |
| BorgWarner | OS1932, OS2366, OS2371, OS2376, OS2381, OS2388, OS2391 |
| Bosch | 16296, 16363, 16400, 16418, 16469, 16515, 16517, 16550, 16559, 16589, 16609, 16586, 16587, 16978, 16982 |
| DENSO | 234-4808, 234-4809, 234-4874 |
| DENSO Auto Parts | 2344823, 234-4808, 234-4809, 234-4874 |
| HELLA | 7.05270.99.0 |
| N/A | 25024432, 2344823, 95560613610, 95560613620, 022906262BH, 022906265B, 06A906262BA, 06C906265, 06C906265A, 06C906265E, 077906262G, 077906265AD, 07C906262A, 07C906262M, 07C906262P, 07D906262B, 07D906262E, 1K0998262B, 250-24689 |
| NTK | 25605 |
| Oextra | REA1704, REA1842, REA1846, REA1851, REA1853, REA1854, REA1858, REA1861 |
| PIERBURG | 705270890, 705270990 |
| Porsche | 955 606 136 10, 955 606 136 20, 958 906 262 D |
| SPECTRA PREMIUM | OS5477 |
| Standard Motor Products | SG1178, SG1533, SG1538, SG1543, SG1548, SG1549, SG1555, SG1558, SG1541 |
| VEMO | V10760015, V10760061, V10760068, V10760091, V10760094 |
| Volkswagen | 022 906 262 BH, 022 906 265 B, 06A 906 262 BA, 06C 906 265, 06C 906 265 A, 06C 906 265 E, 077 906 262 G, 077 906 265 AD, 07C 906 262 A, 07C 906 262 H, 07C 906 262 M, 07C 906 262 P, 07D 906 262 B, 07D 906 262 E, 1K0 998 262 B |
| Walker Products | 250-24432, 250-24494 |
| Wells | SU6534, SU6535, SU6554, SU6607, SU6937 |
DELPHI ES20169 Fits Vehicles
- Volkswagen R32 (2004)
- Audi A8 Quattro (2005-2009)
- Volkswagen Touareg (2004-2006)
- Volkswagen Phaeton (2004-2006)
- Porsche Cayenne (2004-2006)
- Audi TT Quattro (2004-2006)
- Volkswagen Jetta (2002-2004)
- Volkswagen Passat (2002-2004)
- Volkswagen Golf (2002-2005)
