(888) 312-8812 Login SignupDELPHI ES10903 Oxygen Sensor
$21649
Limited availability at this price!
5 Day Lead Time
Get it by Friday, Feb 13
DELPHI ES10903 Part Description
Manufacturer
Product Description
Oxygen Sensor
Features & Benefits
- Delphi planar technology covers older, conical design sensors
- Smart design consolidates SKUs without using long wires
- Patented protective sensor coating helps prevent contamination
- Validated for all fuel types, including ethanol blends like E85
- OE tested to 150,000 miles, plus 2,000 hours severe thermal testing
- Delphi is a global OE manufacturer for oxygen sensor and all oxygen sensors are built to Delphi's OE standards
DELPHI ES10903 Specifications
Product Attributes
| Package Contents | Oxygen Sensor, Instruction Sheet |
| Position(s) | Front, Rear. For the position specific to your vehicle, refer to the Applications. |
| Wiring Harness Length | 40.2 IN |
| Wiring Harness Length | 1020.0 MM |
| Sensor Type | Narrow-Band |
| Terminal Type | Blade |
| Universal Or Specific Fit | Specific |
| Band Type | Narrow |
| Wire Quantity | 4 |
| Grade Type | Standard Replacement |
| Connector Shape | Square |
| Terminal Quantity | 4 |
| Connector Gender | Male |
| Terminal Gender | Male |
| Thread Diameter | 0.7 IN |
| Wrench Size | 22mm |
| Thread Size | M18 - 1.5 |
| Overall Length | 41.3 IN |
| Overall Length | 1050.0 MM |
| Mounting Type | Threaded |
| Thread Diameter | 18.0 MM |
| Wire Gauge Measurement | 20.0 GU |
| Thread Type Standard | Metric |
| Heated | Yes |
Additional Information
| Warranty Distance UOM | DH |
| Warranty Distance | 12000 |
| Harmonized Tariff Code (Schedule B) | 9027100000 |
| Harmonized Tariff Code (HTS) | 9027102000 |
| Warranty Time UOM | MO |
| Warranty Time | 12 |
| Country of Origin (Primary) | CN |
| UPC | 00689604146781 |
| VMRS Code | 045021011 |
| UNSPSC | 41111924 |
DELPHI ES10903 Cross References
| Brand | Part Number |
|---|---|
| BorgWarner | OS1796 |
| Bosch | 13866, 13962 |
| DENSO | 234-4147, 234-4330 |
| DENSO Auto Parts | 234-4147, 234-4330 |
| Ford | BP6G-18-861C9U, BP8K-18-8619U |
| Mazda | BP6G-18-861, BP6G-18-861C, BP6G-18-861C9U, BP8K-18-861, BP8K-18-8619U, JE99-18-86Z9U |
| N/A | 2344147, 2344330, BP6G18861, BP6G18861C, BP8K18861, JE991886Z9U, BP6G18861C9U, BP8K188619U |
| NTK | 24678, 24684 |
| Oextra | REA1623 |
| SPECTRA PREMIUM | OS6069 |
| Standard Motor Products | SG1042, SG1059 |
| Walker Products | 25024641 |
| Wells | SU5800 |
DELPHI ES10903 Fits Vehicles
- Mazda MPV (1996-1998)
- Mazda Miata (2001-2005)
