(888) 312-8812 Login SignupDELPHI GN10229 Ignition Coil
MSRP: $75.83
$4749
Save $28.34
Limited availability at this price!
In Stock
Get it by Wednesday, Feb 25
DELPHI GN10229 Part Description
Manufacturer
Product Description
Ignition Coil
Features & Benefits
- Delphi coils provide OE performance, durability and electromagnetic capacity level requirements
- Delphi ignition coils are designed to insert power into spark plugs to ensure fast starts, consistent engine performance and optimized fuel efficiency
- Delphi uses smart winding process techniques to controls wire lengths, keeping voltage the same
- We manufacture our ignition coils with a high quality wire coating that resists imperfections that lead to failure
DELPHI GN10229 Specifications
Product Attributes
| Notes | Coil comes with Boot |
| Package Contents | Ignition Coil |
| Interface Description | 2 Pin Male Sealed Connector |
| Ignition Type | Standard |
| Coil Type | Plug Top Coil (PTC) |
| Coil Wire Included | No |
| Oil Filled | No |
| Requires External Resistor | No |
| Terminal Type | Pin |
| Mounting Hardware Included | No |
| Wire Quantity | 0 |
| Grade Type | Standard Replacement |
| Mount Type | 1 Mounting Hole |
| Mounting Hole Quantity | 1 |
| Primary Resistance | 0.43 82 |
| Secondary Resistance | 6200.0 82 |
| Terminal Quantity | 2 |
| Connector Gender | Female |
| Terminal Gender | Male |
| Voltage | 12.0 2H |
| Length | 3.189 IN |
| Width | 1.386 IN |
| Height | 5.965 IN |
| Length | 81 MM |
| Width | 35.2 MM |
| Height | 151.5 MM |
| Color | Black |
| Connector Quantity | 1 |
| Connector Shape | Rectangular |
Additional Information
| Warranty Distance UOM | DH |
| Warranty Distance | 36000 |
| Harmonized Tariff Code (Schedule B) | 8511300080 |
| Harmonized Tariff Code (HTS) | 8511300080 |
| Warranty Time UOM | MO |
| Warranty Time | 36 |
| Country of Origin (Primary) | CN |
| UPC | 00689604203408 |
| VMRS Code | 033003001 |
| UNSPSC | 26101769 |
DELPHI GN10229 Cross References
| Brand | Part Number |
|---|---|
| Airtex | 5C1443 |
| BWD | E417 |
| Beck/Arnley | 178-8328 |
| Carquest | 26C1044, 52-1783 |
| DENSO | 673-6010 |
| DENSO Auto Parts | 673-6010 |
| Duralast | C1453 |
| Echlin | IC517 |
| Ford | 4M5Z 12029-A, 4M5Z 12029-B, 4M5Z 12029-BA, 4M5Z 12029-BB, 4M5Z 12029-BC |
| HITACHI | IGC0114, IGC3852-D, IGC3852-S, IGC3852 |
| HOLSTEIN | 2IGC0054 |
| IMC | CLS1042, CLS1044 |
| MasterPro Ignition | 2-50089 |
| Mazda | LF16-18-100, LF16-18-100A, LF16-18-100B, ZZCA-18-100 |
| Motorcraft | DG-541 |
| N/A | LF1618100, LF1618100A, LF1618100B, ZZCA18100, 72932006, 1788328, FD505, 4M5Z12029A, 4M5Z12029B, 4M5Z12029BA, 4M5Z12029BB, 4M5Z12029BC, DG501, DG504, DG507, DG541, E417, 601006, 921X2065 |
| NAPA Mileage Plus | IC517SB |
| NGK SPARK PLUGS | U5019, 48846 |
| Original Engine Management | 50089 |
| PRENCO | 36-8053 |
| Richporter | C-676 |
| STANDARD IGNITION | FD505 |
| Spectra Premium | C-676 |
| Standard Motor Products | FD-505 |
| VEMO | V25700005 |
| WALKER PRODUCTS | 921-2065-4, 928-4079-4 |
| WPS World Power Systems | CFD505 |
| Walker Products | 921-2065 |
| Wells | C1453 |
DELPHI GN10229 Fits Vehicles
- Ford Transit Connect (2010-2013)
- Mazda 6 (2005)
- Mercury Mariner (2005-2008)
- Mazda Tribute (2005-2006, 2008)
- Ford Escape (2005-2008)
- Mazda 3 (2004-2005)
- Ford Focus (2003-2011)
