(888) 312-8812 Login SignupDELPHI HP10216 Fuel Pump Hanger Assembly
MSRP: $453.63
$37849
Save $75.14
Limited availability at this price!
In Stock
Get it by Monday, Feb 9
DELPHI HP10216 Part Description
Manufacturer
Product Description
Fuel Pump Hanger Assembly
Features & Benefits
- Delphi is a global OE manufacturer and all fuel pumps are built to Delphi's OE standards
- Delphi pumps are designed to operate under extreme temperatures with quick engine starts
- Metal tubes in Delphi hangers are routed so as to not contact the tank at any point eliminating noise and vibration during vehicle operation
- Empty float height and float retention matches OE specifications and guarantees correct gas gauge reading
- Restores fast pressure performance and system integrity, translating to better pumping through less energy
- Lower failure rates due to its innovative design and durability
- Part is validated, tested and matched to the right vehicle application
- Lower amperage draws less load on vehicle's electrical system
- Always be sure to check and clean fuel tank to avoid unnecessary returns
DELPHI HP10216 Specifications
Product Attributes
| Package Contents | Fuel Pump Hanger Assembly w/Float Arm, Seal, (6) Nuts, (6) Washers, (2) Retainer Clips, Instruction Sheet |
| Fuel Level Sender Assembly Included | Yes |
| Item Grade | Standard Replacement |
| System Pressure | 44 psi |
| Outlet Outside Diameter | 0.375 IN |
| Voltage | 12.0 2H |
| Fuel Type | Gas |
| Maximum Pressure | 109.0 PS |
| Terminal Type | Pin |
| Gasket Or Seal Included | Yes |
| Terminal Quantity | 4 |
| Terminal Gender | Male |
| Strainer Included | Yes |
| Inlet Type | Strainer |
| Outlet Type | Quick Connect |
| Outlet Quantity | 2 |
| In Tank or External | In Tank |
| Resistance Ohms Empty | 15.0 82 |
| Resistance Ohms Full | 160.0 82 |
| Internal Or External Strainer | External |
| Pump Type | Electric |
| Average Current Draw | 10.0 68 |
| Average Flow Rating | 26.0 GPH |
| Material | Metal |
| Fuel Sending Unit Included | Yes |
| Negative Ground | No |
| Mounting Hardware Included | Yes |
| Grade Type | Premium |
| Connector Shape | Round |
| Lock Ring Included | No |
| Connector Gender | Female |
| Inlet Quantity | 1 |
| Fuel Pump Included | Yes |
| Gasket Or Seal Material | Nitrile Rubber |
| Minimum Pressure | 44 PS |
| Pump Design | Turbine |
| Fuel Tank Pressure Sensor Included | No |
| Universal Or Specific Fit | Specific |
Additional Information
| Harmonized Tariff Code (HTS) | 8413309030 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| Harmonized Tariff Code (Schedule B) | 8413309000 |
| Country of Origin (Primary) | CN |
| UPC | 00689604233702 |
| VMRS Code | 044003257 |
| UNSPSC | 40151532 |
DELPHI HP10216 Cross References
| Brand | Part Number |
|---|---|
| AUTOBEST | F1448A |
| Airtex | E2437S |
| AutoZone | DHP10216 |
| CARTER FUEL PUMPS | P76545H |
| Carter | P76304, P76545H |
| DENSO Auto Parts | 953-4033 |
| EVO Driveline | AFS0903S, RE0903S |
| Ford | 4C2Z 9H307-CB, 6C2Z 9H307-CA |
| GMB | 525-6040 |
| Motorcraft | PFS-298 |
| N/A | 4C2Z9H307CB, 6C2Z9H307CA, P76545S, USEP2437S, F1448A, D0095H |
| Precision Fuel | A30138 |
| Spectra Premium | SP1396, SP2091H |
| TYC | 150141-A |
DELPHI HP10216 Fits Vehicles
- Ford E-450 Super Duty (2004-2008)
- Ford E-350 Super Duty (2004-2008)
- Ford E-250 (2004-2008)
- Ford E-350 Club Wagon (2004-2005)
- Ford E-150 Club Wagon (2004)
- Ford E-150 (2004)
