(888) 312-8812 Login SignupDELPHI FG1149 Fuel Pump Module Assembly
$35899
Limited availability at this price!
In Stock
Get as soon as Monday, Sep 21
DELPHI FG1149 Part Description
Manufacturer
Product Description
Fuel Pump Module Assembly
Features & Benefits
- Delphi is a global OE manufacturer and all fuel pumps are built to Delphi's OE standards
- Empty float height and float retention matches OE specifications and guarantees correct gas gauge reading
- Lower amperage draws less load on vehicle's electrical system
- Part is validated, tested and matched to the right vehicle application
- Always be sure to check and clean fuel tank to avoid unnecessary returns
- Lower failure rates due to its innovative design and durability
DELPHI FG1149 Specifications
Product Attributes
| System Pressure | 51 psi |
| Package Contents | Fuel Pump Module Assembly w/Float Arm, Seal, Instruction Sheet |
| Item Grade | Standard Replacement |
| Fuel Level Sender Assembly Included | Yes |
| Vapor Pressure Sensor | No |
| Outlet Outside Diameter | 0.375 IN |
| Voltage | 13 2H |
| Fuel Type | Gas |
| Regulator Included | Yes |
| Maximum Pressure | 80 PS |
| Terminal Type | Blade |
| Gasket Or Seal Included | Yes |
| Terminal Quantity | 5 |
| Lock Ring Included | No |
| Terminal Gender | Male |
| Strainer Included | Yes |
| Inlet Type | Strainer |
| Outlet Type | Quick Connect |
| Outlet Quantity | 1 |
| In Tank or External | In Tank |
| Resistance Ohms Empty | 80 82 |
| Resistance Ohms Full | 5 82 |
| Internal Or External Strainer | Internal |
| Pump Type | Electric |
| Average Current Draw | 7 68 |
| Average Flow Rating | 20 GPH |
| Fuel Sending Unit Included | Yes |
| Negative Ground | No |
| Mounting Hardware Included | No |
| Grade Type | Premium |
| Connector Quantity | 1 |
| Connector Shape | Rectangle |
| Housing Material | Plastic |
| Installation Warnings | No |
| Connector Gender | Female |
| Fuel Filter Included | Yes |
| Gasket Or Seal Material | Nitrile Rubber |
| Minimum Pressure | 51 PS |
| Wire Harness Included | No |
| Pump Design | Turbine |
| Fuel Tank Pressure Sensor Included | No |
| Universal Or Specific Fit | Specific |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8413309000 |
| Harmonized Tariff Code (HTS) | 9026102080 |
| Warranty Special | Limited |
| Warranty Special UOM | LT |
| Country of Origin (Primary) | TH |
| UPC | 00689604226483 |
| VMRS Code | 044003258 |
| UNSPSC | 25172409 |
DELPHI FG1149 Cross References
| Brand | Part Number |
|---|---|
| Airtex | E8855M |
| AutoZone | CFG1149 |
| CARTER FUEL PUMPS | P76612M |
| Carquest | M2480552 |
| Carter | P76612M, P77095M |
| Datsun/Nissan | 17040-1FC0A, 17040-1FC0B, 17040-9EG0B, 17040-9EG0C, 17040-EM30A, 17040-EM31A, 17040-ZR70B, 25060-1FC0A, 25060-1FC1A, 25060-1FC1B |
| GMB | 550-2090 |
| Import Direct | A38009 |
| N/A | 170401FC0B, 170409EG0B, 170409EG0C, 17040EM30A, 17040EM31A, 17040ZR70B, USEP8855M, F4866A, C0701M, 4010648, 4011424 |
| Spectra Premium | SP4022M, SP4099M |
| TYC | 150314-A |
DELPHI FG1149 Fits Vehicles
- Nissan Cube (2009-2014)
- Nissan Versa (2007-2012)
