DELPHI FG0950 Fuel Pump Module Assembly

★★★★★ (0)
Delphi FG0950 Fuel Pump Module Assembly Fuel Pump Module Assembly
DELPHI
SHIPS TODAY

$341.49

Limited availability at this price!

In Stock

Get as soon as Tuesday, Nov 17
30-day Return Policy On eligible items Details
Does not qualify towards free shipping promotion details

DELPHI FG0950 Part Description

Manufacturer

DELPHI

Product Description

Fuel Pump Module Assembly

Features & Benefits

  • Delphi is a global OE manufacturer and all fuel pumps are built to Delphi's OE standards
  • Empty float height and float retention matches OE specifications and guarantees correct gas gauge reading
  • Lower amperage draws less load on vehicle's electrical system
  • Part is validated, tested and matched to the right vehicle application
  • Always be sure to check and clean fuel tank to avoid unnecessary returns
  • Lower failure rates due to its innovative design and durability

DELPHI FG0950 Specifications

Product Attributes

Vapor Pressure SensorNo
Item GradeStandard Replacement
Fuel Level Sender Assembly IncludedYes
Package ContentsFuel Pump Module Assembly w/Float Arm, Clips, Instruction Sheet
System Pressure44 psi
Outlet Outside Diameter0.375 IN
Voltage12 2H
Fuel TypeGas
Regulator IncludedNo
Maximum Pressure80 PS
Terminal TypePin
Gasket Or Seal IncludedYes
Terminal Quantity4
Lock Ring IncludedNo
Terminal GenderMale
Strainer IncludedYes
Inlet TypeStrainer
Outlet TypeQuick Connect
Outlet Quantity2
In Tank or ExternalIn Tank
Resistance Ohms Empty15 82
Resistance Ohms Full160 82
Internal Or External StrainerExternal
Pump TypeElectric
Average Current Draw9 68
Average Flow Rating29 GPH
Fuel Sending Unit IncludedYes
Negative GroundNo
Mounting Hardware IncludedNo
Grade TypePremium
Connector Quantity1
Connector ShapeRound
Housing MaterialPlastic
Installation WarningsNo
Connector GenderFemale
Fuel Filter IncludedNo
Gasket Or Seal MaterialNitrile Rubber
Minimum Pressure44 PS
Wire Harness IncludedNo
Pump DesignTurbine
Fuel Tank Pressure Sensor IncludedNo
Universal Or Specific FitSpecific

Additional Information

Harmonized Tariff Code (Schedule B)8413309000
Harmonized Tariff Code (HTS)9026102080
Warranty SpecialLimited
Warranty Special UOMLT
Country of Origin (Primary)TH
UPC00689604212042
VMRS Code044003258
UNSPSC25172409

DELPHI FG0950 Cross References

BrandPart Number
AirtexE2234M, E2312
AutoZoneDFG0950
Bosch67184
CarterP74942M
DENSO Auto Parts953-4016
EVO DrivelineAFS0232S, RE0232S, AFS0237S, AFS0995P, RE0237S, RE0995P
Ford3C3Z 9H307-DA, 3C3Z 9H307-DB, F81Z 9H307-DA, F81Z 9H307-DD, F81Z 9H307-DE
GMB525-2920
MotorcraftPFS-271
N/A9534016, 3C3Z9H307DA, 3C3Z9H307DB, F81Z9H307DA, F81Z9H307DD, F81Z9H307DE, PFS271, USEP2234M, C0025M, 4010227, 4010235
Precision FuelA30217
SPECTRA PREMIUMSP2334M
Spectra PremiumSP1253, SP2234M
WalbroTU254

DELPHI FG0950 Fits Vehicles

  • Ford F-350 Super Duty (1999-2004)
  • Ford F-450 Super Duty (1999-2004)
  • Ford F-550 Super Duty (1999-2004)
