CENTRIC 120.04006 Part Description
Manufacturer
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
CENTRIC 120.04006 Specifications
Product Attributes
| Vane Style [cntrc] | Pillar |
| Disc Mounting [cntrc] | Floating |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Hat Id [cntrc] Mm | 124.500 |
| OEM Vane Count [cntrc] | 93 |
| Product Grade [cntrc] | Premium |
| Weight [cntrc] Lbs | 17.950 |
| Hat Id [cntrc] In | 4.902 |
| Misc Holes [cntrc] | 5 |
| Weight [cntrc] Kgs | 8.160 |
| Discard Thickness | 25.500 MM |
| Discard Thickness | 1.004 IN |
| Nominal Thickness | 1.102 IN |
| Nominal Thickness | 28.000 MM |
| Hat Finish | Coated |
| Overall Height | 45.700 MM |
| Overall Height | 1.799 IN |
| Outside Diameter | 12.008 IN |
| Outside Diameter | 305.000 MM |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 2.323 IN |
| Center Hole Diameter | 59.000 MM |
| Mounting Bolt Hole Circle Diameter | 3.858 IN |
| Mounting Bolt Hole Circle Diameter | 98.000 MM |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 13.000 MM |
| Stud/Lug Hole Diameter | 0.512 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 805890966869 |
CENTRIC 120.04006 Part Interchanges
| Brand | Part Number |
|---|---|
| Raybestos Brakes | 781770, 781770FZN, 781770R |
| Neotek Premium Drums and Rotors | 1067612GF |
| N/A | 850369, BR901326, 45637, 45637G, 90007006, 0051914663, 68201086AA, 72116 |
CENTRIC 120.04006 Fits Vehicles
- Fiat 500L (2014-2020)
CENTRIC 120.04006 Cross References
We have 4 alternatives for the 120.04006 by CENTRIC:
