DAYCO PB1710N Part Description
DAYCO PB1710N Specifications
Product Attributes
| Overall Outside Diameter | --- - '5.867' in |
| Overall Outside Diameter | --- - '149.0' mm |
| Crank Bore | --- - '1.497' in |
| Crank Bore | --- - '38.0' mm |
| Overall Width | --- - '1.497' in |
| Overall Width | --- - '38.0' mm |
| Nose Outside Diameter | --- - '0' in |
| Nose Outside Diameter | --- - '0.00' mm |
| Ring Width | --- - '1.497' in |
| Ring Width | --- - '38.0' mm |
| Bolt Hole Quantity | --- - '4' |
| Crank Trigger/Exciter Plate | --- - 'No' |
| Woodruff Key Included | --- - 'No' |
| Hardware Included | --- - 'No' |
| Counterweight Balance | --- - Neutral, no counterweight |
| Timing Marks | --- - 'Yes' |
| Installation Instructions Included | --- - 'No' |
| Number of Integrated Pulleys | --- - '2' |
| Pulley 1 Type | --- - Serpentine |
| Pulley 1 Outside Diameter | --- - '5.670' in |
| Pulley 1 Outside Diameter | --- - '144.0' mm |
| Pulley 1 Number Of Grooves | --- - '4' mm |
| Pulley 2 Type | --- - Serpentine |
| Pulley 2 Outside Diameter | --- - '5.079' in |
| Pulley 2 Outside Diameter | --- - '129.0' mm |
| Pulley 2 Number Of Grooves | --- - '4' mm |
| Outer Ring Material | --- - Cast Iron |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 8483508080 |
DAYCO PB1710N Cross References
| Brand | Part Number |
|---|---|
| DORMAN | 594-380 |
DAYCO PB1710N Customer Reviews
No reviews yet
Be the first to review this product!
DAYCO PB1710N Manufacturer Information
For over 100 years, Dayco® has been a world leader in the development, manufacture, and distribution of essential engine drive components for the aftermarket sector. Its catalog covers a wide range of drive system components for various applications, including automotive, truck, construction, agriculture, industrial machinery, and hybrid electric vehicles. For heavy duty trucks and buses, Dayco specializes in serpentine and V-belts, vibration dampers, thermostats, water pumps, expansion tanks, and gaskets. Dayco parts are built with durability in mind, using high-grade materials and tested in compliance with the latest standards set by the automotive industry. These result in parts that are superior in reliability, performance, and service life over the competition.
