Name: Electronic Specialties 687 Low Current AC/DC Clamp Meter
SKU: 687
Price: 267.99 USD
Availability: InStock

ELECTRONIC SPECIALTIES part description

California Proposition 65 Warning

WARNING: This product can expose you to chemical which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information, go to www.P65Warnings.ca.gov. (Read more)

Features and Benefits

With the capability of measuring down to 1 milliamp (.001A), the #687 is a great tool for all low current applications. Especially for diagnosing parasitic drains! Clamp opening is large enough to fit over most negative battery cables. Applications: fuel injectors, fuel pumps, electric motors, battery drains, charging systems.
35 Test Ranges
10 Test Functions
Auto Power Off
Auto-Ranging
Data Hold
Continuity Beep
Overload Protection
Clamp opening 5/8 inches
9 Volt Battery Included
Carrying Case included
DC Amps: 0-4A, 80A
AC Amps: 0-4A, 80A
DC Volts: 0-400mV, 4V, 40V, 400V, 600V
AC Volts: 0-400mV, 4V, 40V, 400V, 600V
Ohms: 0-400, 4k, 40k, 400k, 4M, 40M
Frequency: 0-5Hz, 50Hz, 500Hz, 5kHz, 50kHz, 500kHz, 5MHz, 10MHz
Capacitance: 0-40nF, 400nF, 4uF, 40uF, 100uF
Duty Cycle: 0-.5%-99.0%
Diode: Diode Test
Continuity: Audible Beep

Since 1967, Electronic Specialties, Inc.® has been designing, engineering, and manufacturing high-quality test instruments for automotive, marine, HVAC, small engine, and industrial applications. Its innovative and time-saving products have already won various awards and patents, such as the Top 20 Tools in 2015 for its Starter Buddy, a tool used primarily in testing the health of the vehicle’s entire electrical starting/cranking circuit. Other award-winning products from this brand include the Max Fuse Buddy, Fuse Buddy Pro Test Kit, Low Current Probe/DMM, Load Pro, Relay Buddy, Short Buddy® Audible Trouble Shooter, and True RMS Low Current Clamp Meter. Electronic Specialties’ headquarters is located in Genoa City, Wisconsin.
