(888) 312-8812 Login SignupRAYBESTOS 980980R Raybestos R-Line Brake Rotor
MSRP: $61.28
$4349
Save $17.79
Limited availability at this price!
In Stock
Get it by Friday, Jul 3
RAYBESTOS 980980R Part Description
Manufacturer
Product Description
Raybestos R-Line Brake Rotor
Application Summary
2022-2011 Hyundai Accent Rear, 2022-2012 Kia Rio Rear, 2014-2013 Dodge Attitude Rear
Features & Benefits
- OE Fit, Form, and Function
- Developed from OE samples and made with G3000-qualified material, ensuring OE fit, form and function for dependable braking.
- SAE Standard
- R-Line Rotors meet the SAE standard for tensile strength, providing structural integrity and a maximum service life.
- Low Initial Lateral Runout and Thickness Variation
- R-Line Rotors have a small parameter lateral runout and a thickness variation ensuring less pedal pulsation, less brake noise, and an extended pad life.
- Mill Balanced Edges
- R-Line Rotors are mill balanced and 100 percent validated. This helps minimize the thickness variation on the rotor and leads to minimized vibration and smoother stopping.
RAYBESTOS 980980R Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.46 IN |
| Center Hole Diameter | 62.5 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Discard Thickness | 0.331 IN |
| Discard Thickness | 8.4 MM |
| Harmonize Code | 8708.30.5030 |
| Inside Diameter | 6.988 IN |
| Inside Diameter | 177.5 MM |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 3.93 IN |
| Mounting Bolt Hole Circle Diameter | 99.8 MM |
| Mounting Bolt Hole Diameter | 0.487 IN |
| Mounting Bolt Hole Diameter | 12.35 MM |
| Mounting Bolt Hole Quantity | 4 |
| Nominal Thickness | 0.394 IN |
| Nominal Thickness | 10 MM |
| Outside Diameter | 10.315 IN |
| Outside Diameter | 262 MM |
| Overall Height | 1.74 IN |
| Overall Height | 44.2 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Solid |
| Stud/Lug Hole Quantity | 4 |
| Surface Type | Smooth |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00887213028027 |
RAYBESTOS 980980R Cross References
| Brand | Part Number |
|---|---|
| ADVANCE AUTO PARTS | YH421757, YH421757C, YH421757P |
| ATE BRAKE PRODUCTS | 410398 |
| AUTOPARTSOURCE | 482570 |
| AUTOXTRA | AX901094 |
| AUTOZONE | 70114, 70114DG, 70114DL |
| Autoxtra | AX901094P |
| BENDIX | PRT6147 |
| BRAKEBEST | 980980R, 980980RGS |
| CENTRIC | 120.51047, 120.51047CRY, 121.51047, 126.51047SL, 126.51047SR, 127.51047L, 127.51047R, 128.51047L, 128.51047R, 320.51047 |
| Centric Parts | 120.51047, 120.51047CRY, 121.51047, 126.51047SL, 126.51047SR, 127.51047L, 127.51047R, 128.51047L, 128.51047R, 320.51047 |
| DURA CORP | BR901094 |
| DuraGo | BR901094, BR90109402 |
| KIA | 584110U300, K584110U300 |
| MAGMA PRODUCTS | PMR285084 |
| NAPA BRAKES | SDK6703 |
| NEWTEK AUTOMOTIVE | 31612 |
| Newtek Automotive USA | 31612 |
| POWERSTOP | JBR1565EVC |
| Qualis | 44744 |
| TopNotch | TN980980GEO |
| UAP | 2901094, U490109 |
| Ultra Brake | HY-3024 |
| WAGNER BRAKE | BD180496 |
| WORLDPAC | 1407-421757, 1427-586878 |
| WORLDPARTS | WS1-331612 |
| Wagner Brake | BD180496E |
| Winhere | 661953 |
RAYBESTOS 980980R Fits Vehicles
- Dodge Attitude (2013-2014)
- Kia Rio (2012-2023)
- Hyundai Accent (2011-2022)
