RAYBESTOS 980940 Part Description
Manufacturer
Product Description
Raybestos Specialty - Street Performance Brake Rotor
Application Summary
2017-2013 Audi Q5 Front, 2020-2017 Porsche Macan Front, 2015-2012 Audi A6 Quattro Front, 2016-2011 Audi S4 Front, 2015-2012 Audi A7 Quattro Front, 2017-2012 Audi S5 Front, 2015-2012 Audi A6 Front, 2012 Audi A5 Quattro Front
Features & Benefits
- Application Specific Enhanced Iron
- Raybestos® Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Raybestos(R) Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Cooling Vanes
- The cooling vanes match OE configurations and provide optimal cooling and reduced fade.
- Application Specific Coating
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0® coating on the entire rotor
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0(R) coating on the entire rotor
- Black fusion coating on the rotor hat and Grey Fusion 4.0® coating on the rotor inboard surface and cooling vanes
- Black fusion coating on the rotor hat and Grey Fusion 4.0(R) coating on the rotor inboard surface and cooling vanes
- Turned Finish
- Turned finish minimizes noise and improves responsiveness for smoother stops.
- S-Groove Slot
- Depending on the application, some Raybestos® Performance Rotors are designed with a patented S-Groove Slot.
- Depending on the application, some Raybestos(R) Performance Rotors are designed with a patented S-Groove Slot.
RAYBESTOS 980940 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.677 IN |
| Center Hole Diameter | 68 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 1.102 IN |
| Discard Thickness | 28 MM |
| Harmonize Code | 8708.30.5030 |
| Inside Diameter | 8.268 IN |
| Inside Diameter | 210 MM |
| Mounting Bolt Hole Circle Diameter | 4.409 IN |
| Mounting Bolt Hole Circle Diameter | 112 MM |
| Mounting Bolt Hole Diameter | 0.595 IN |
| Mounting Bolt Hole Diameter | 15.1 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 1.177 IN |
| Nominal Thickness | 29.9 MM |
| Outside Diameter | 13.575 IN |
| Outside Diameter | 344.8 MM |
| Overall Height | 2.055 IN |
| Overall Height | 52.2 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| Surface Type | Smooth |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00829352984628 |
RAYBESTOS 980940 Cross References
| Brand | Part Number |
|---|---|
| ADVANCE AUTO PARTS | YH335136, YH335136C, YH335136P |
| ATE BRAKE PRODUCTS | SP30222, 430222 |
| AUDI | 4G0615301, 4G0615301AF, 4G0615301G, 4G0615301M, 4G0615301Q |
| AUTOZONE | 78018, 78018DG |
| AutoZone | 78018DL |
| BOSCH | 14011526 |
| BRAKEBEST | 14011526, 980940, 980940RGS |
| Brembo | 09.B970.11, 09.B970.1S |
| CENTRIC | 120.33138, 121.33138, 125.33138, 125.33138CRY, 126.33138CSL, 126.33138CSR, 126.33138SL, 126.33138SR, 127.33138CL, 127.33138CR, 127.33138L, 127.33138R, 128.33138CL, 128.33138CR, 128.33138L, 128.33138R, 227.33138L, 227.33138R, 320.33138, 320.33138C, 320.33138H |
| Centric Parts | 120.33138, 121.33138, 125.33138, 125.33138CRY, 126.33138CSL, 126.33138CSR, 126.33138SL, 126.33138SR, 127.33138CL, 127.33138CR, 127.33138L, 127.33138R, 128.33138CL, 128.33138CR, 128.33138L, 128.33138R, 227.33138L, 227.33138R, 320.33138C, 320.33138, 320.33138H |
| DURA CORP | BR34498 |
| Dura Corp | BR901402 |
| DuraGo | BR901402 |
| MAGMA PRODUCTS | PSR585115 |
| NAPA BRAKES | SDK6776 |
| PAGID | 355123112 |
| PAGID Racing | 355123112 |
| PORSCHE | 95B615301B, 95B615301M |
| POWERSTOP | EBR1210EVC |
| PROMAX | 14-34498 |
| Qualis | 45585 |
| TopNotch | TN980940GEO |
| VAICO | V1080118 |
| VOLKSWAGEN | 4G0615301AE |
| WORLDPAC | 1407-335136, 1427-545601 |
| Wagner Brake | BD180854E |
| Winhere | 6621358, 6621781 |
RAYBESTOS 980940 Fits Vehicles
- Porsche Macan (2015-2025)
- Audi Q5 (2013-2017)
- Audi A4 Quattro (2013)
- Audi A6 (2012-2018)
- Audi A5 Quattro (2012-2013)
- Audi S5 (2012-2017)
- Audi A6 Quattro (2012-2019)
- Audi A5 (2012-2013, 2016)
- Audi A7 Quattro (2012-2018)
- Audi S4 (2011-2016)
