RAYBESTOS 680983 Part Description
Manufacturer
Product Description
Raybestos Specialty - Street Performance Coated Brake Rotor
Application Summary
2019-2013 Ford Explorer Rear, 2019-2013 Ford Taurus Rear, 2019-2012 Ford Flex Rear, 2019-2013 Ford Police Interceptor Utility Rear, 2019-2013 Ford Police Interceptor Sedan Rear, 2016-2012 Lincoln MKS Rear, 2019-2013 Lincoln MKT Rear
Features & Benefits
- Application Specific Enhanced Iron
- Raybestos® Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Raybestos(R) Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Cooling Vanes
- The cooling vanes match OE configurations and provide optimal cooling and reduced fade.
- Application Specific Coating
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0® coating on the entire rotor
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0(R) coating on the entire rotor
- Black fusion coating on the rotor hat and Grey Fusion 4.0® coating on the rotor inboard surface and cooling vanes
- Black fusion coating on the rotor hat and Grey Fusion 4.0(R) coating on the rotor inboard surface and cooling vanes
- Turned Finish
- Turned finish minimizes noise and improves responsiveness for smoother stops.
- S-Groove Slot
- Depending on the application, some Raybestos® Performance Rotors are designed with a patented S-Groove Slot.
- Depending on the application, some Raybestos(R) Performance Rotors are designed with a patented S-Groove Slot.
RAYBESTOS 680983 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.68 IN |
| Center Hole Diameter | 68.05 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Discard Thickness | 0.689 IN |
| Discard Thickness | 17.5 MM |
| Harmonize Code | 8708.30.5030 |
| Inside Diameter | 9.6 IN |
| Inside Diameter | 243.85 MM |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 4.5 IN |
| Mounting Bolt Hole Circle Diameter | 114.3 MM |
| Mounting Bolt Hole Diameter | 0.573 IN |
| Mounting Bolt Hole Diameter | 14.55 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 0.748 IN |
| Nominal Thickness | 19 MM |
| Outside Diameter | 13.579 IN |
| Outside Diameter | 344.9 MM |
| Overall Height | 1.524 IN |
| Overall Height | 38.7 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| Surface Type | Smooth |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00887213026405 |
RAYBESTOS 680983 Cross References
| Brand | Part Number |
|---|---|
| ADVANCE AUTO PARTS | G15591SD, YH477754, YH477754C |
| AUTOPARTSOURCE | 492129 |
| AUTOXTRA | AX901160 |
| AUTOZONE | 75011, 75011DG, 75011DL |
| Advance Auto Parts | YH477754P |
| Autoxtra | AX901160P |
| BENDIX | PRT6202, SDR5898 |
| BRAKEBEST | 680983, 680983P, 680983R, 680983RGS |
| Brembo | 09.D275.11 |
| CENTRIC | 120.65137, 120.65137CRY, 121.65137, 126.65137CSL, 126.65137CSR, 126.65137SL, 126.65137SR, 127.65137L, 127.65137R, 128.65137L, 128.65137R, 320.65137, 320.65137F, 321.65137 |
| Centric Parts | 120.65137, 120.65137CRY, 121.65137, 126.65137CSL, 126.65137CSR, 126.65137SL, 126.65137SR, 127.65137L, 127.65137R, 128.65137L, 128.65137R, 320.65137, 320.65137F, 321.65137 |
| DURA CORP | BR54189, BR901160 |
| DuraGo | BR901160, BR90116002, BR901160-02, BR901160-03 |
| Dynamic Friction Company | 604-54222 |
| Eurorotor | 54196 |
| FORD | DG1Z2C026A |
| Ford | EU2Z2V026B |
| MAGMA PRODUCTS | PSR205248 |
| MOTORCRAFT | BRRF92 |
| Motorcraft | NBRR10, BRR253 |
| NEOTEK | 1071115GF |
| NEWTEK AUTOMOTIVE | R1160 |
| Newtek Automotive USA | R1160 |
| PROMAX | 14-54189 |
| PRONTO | BR901160 |
| Parts Master | 901160 |
| Performance Friction | 343.039.01 |
| PowerStop | AR85142, AR85142EVC |
| Qualis | 42285 |
| TopNotch | TN680983GEO |
| WABCO | PS901160 |
| WABCO - Archived | PS901160 |
| WAGNER | BD180536E |
| WAGNER BRAKE | BD180536, BD180536E |
| WINHERE | 6621454 |
| WORLDPAC | 1407-477754, 1427-731822 |
| WORLDPARTS | WS1-154189 |
RAYBESTOS 680983 Fits Vehicles
- Ford Police Responder Hybrid (2019-2020)
- Ford Special Service Police Sedan (2014-2018)
- Ford Police Interceptor Utility (2013-2019)
- Ford Police Interceptor Sedan (2013-2019)
- Lincoln MKT (2013-2019)
- Ford Taurus (2013-2019)
- Ford Explorer (2013-2019)
- Lincoln MKS (2012-2016)
- Ford Flex (2012-2019)
