(888) 312-8812 Login SignupDELPHI FG0963 Fuel Pump Module Assembly
MSRP: $403.64
$31549
Save $88.15
Limited availability at this price!
In Stock
Get it by Thursday, Feb 12
DELPHI FG0963 Part Description
Manufacturer
Product Description
Fuel Pump Module Assembly
Features & Benefits
- Delphi is a global OE manufacturer and all fuel pumps are built to Delphi's OE standards
- Empty float height and float retention matches OE specifications and guarantees correct gas gauge reading
- Lower amperage draws less load on vehicle's electrical system
- Part is validated, tested and matched to the right vehicle application
- Always be sure to check and clean fuel tank to avoid unnecessary returns
- Lower failure rates due to its innovative design and durability
DELPHI FG0963 Specifications
Product Attributes
| Fuel Level Sender Assembly Included | Yes |
| Package Contents | Fuel Pump Module Assembly w/Float Arm, Seal, Lock Ring, Instruction Sheet |
| Vapor Pressure Sensor | No |
| Item Grade | Standard Replacement |
| System Pressure | 49 psi |
| Outlet Outside Diameter | 0.375 IN |
| Voltage | 12 2H |
| Fuel Type | Gas |
| Regulator Included | Yes |
| Maximum Pressure | 55 PS |
| Terminal Type | Blade |
| Gasket Or Seal Included | Yes |
| Terminal Quantity | 4 |
| Lock Ring Included | Yes |
| Terminal Gender | Male |
| Strainer Included | Yes |
| Inlet Type | Strainer |
| Outlet Type | Quick Connect |
| Outlet Quantity | 1 |
| In Tank or External | In Tank |
| Resistance Ohms Empty | 131 82 |
| Resistance Ohms Full | 12 82 |
| Internal Or External Strainer | Internal |
| Pump Type | Electric |
| Average Current Draw | 14 68 |
| Average Flow Rating | 13 GPH |
| Fuel Sending Unit Included | Yes |
| Negative Ground | No |
| Mounting Hardware Included | No |
| Grade Type | Premium |
| Connector Quantity | 1 |
| Connector Shape | Trapezoid |
| Housing Material | Plastic |
| Installation Warnings | No |
| Connector Gender | Female |
| Fuel Filter Included | Yes |
| Gasket Or Seal Material | Nitrile Rubber |
| Minimum Pressure | 49 PS |
| Wire Harness Included | No |
| Pump Design | Turbine |
| Fuel Tank Pressure Sensor Included | No |
| Universal Or Specific Fit | Specific |
Additional Information
| Harmonized Tariff Code (HTS) | 8413309030 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| Harmonized Tariff Code (Schedule B) | 8413309000 |
| Country of Origin (Primary) | TH |
| UPC | 00689604214725 |
| VMRS Code | 044003258 |
| UNSPSC | 25172409 |
DELPHI FG0963 Cross References
| Brand | Part Number |
|---|---|
| Airtex | E8655M, E8733M, E8335, E8426 |
| AutoZone | DFG0963 |
| Bosch | 67906, 67950 |
| CARTER FUEL PUMPS | P76394M |
| Carquest | M2425076 |
| Carter | P76028, P76394M, P88023 |
| DENSO Auto Parts | 950-0116, 951-0005 |
| EVO Driveline | AFS0894P, AFS0925P, RE0925P |
| GMB | 535-2110 |
| Honda | 17040-SCA-000, 17045-S9A-A00, 17045-S9A-A30 |
| Import Direct | A27127, E16009 |
| N/A | 9510005, 17040SCA000, 17045S9AA00, 17045S9AA30, C0665M, 4010502, 4011058 |
| Spectra Premium | SP8024M, SP1126, SP1173, SP8037M |
| TYC | 150400-A |
DELPHI FG0963 Fits Vehicles
- Honda CR-V (2002-2006)
