(888) 312-8812 Login SignupDELPHI FG0880 Fuel Pump Module Assembly
MSRP: $511.41
$30599
Save $205.42
Limited availability at this price!
In Stock
Get it by Friday, Feb 6
DELPHI FG0880 Part Description
Manufacturer
Product Description
Fuel Pump Module Assembly
Features & Benefits
- Delphi is a global OE manufacturer and all fuel pumps are built to Delphi's OE standards
- Empty float height and float retention matches OE specifications and guarantees correct gas gauge reading
- Lower amperage draws less load on vehicle's electrical system
- Part is validated, tested and matched to the right vehicle application
- Always be sure to check and clean fuel tank to avoid unnecessary returns
- Lower failure rates due to its innovative design and durability
DELPHI FG0880 Specifications
Product Attributes
| System Pressure | 59 psi |
| Package Contents | Fuel Pump Module Assembly w/Float Arm, Instruction Sheet |
| Fuel Level Sender Assembly Included | Yes |
| Vapor Pressure Sensor | No |
| Item Grade | Standard Replacement |
| Position(s) | Left |
| Outlet Outside Diameter | 0.375 IN |
| Voltage | 12 2H |
| Fuel Type | Gas |
| Regulator Included | No |
| Maximum Pressure | 73 PS |
| Terminal Type | Blade |
| Gasket Or Seal Included | Yes |
| Terminal Quantity | 4 |
| Lock Ring Included | No |
| Terminal Gender | Male |
| Strainer Included | Yes |
| Inlet Type | Strainer |
| Outlet Type | Quick Connect |
| Outlet Quantity | 1 |
| In Tank or External | In Tank |
| Resistance Ohms Empty | 15 82 |
| Resistance Ohms Full | 160 82 |
| Internal Or External Strainer | External |
| Pump Type | Electric |
| Average Current Draw | 10 68 |
| Average Flow Rating | 26 GPH |
| Fuel Sending Unit Included | Yes |
| Negative Ground | No |
| Mounting Hardware Included | No |
| Grade Type | Premium |
| Connector Quantity | 1 |
| Connector Shape | Square |
| Housing Material | Plastic |
| Installation Warnings | No |
| Connector Gender | Female |
| Fuel Filter Included | No |
| Gasket Or Seal Material | Nitrile Rubber |
| Minimum Pressure | 59 PS |
| Wire Harness Included | No |
| Pump Design | Turbine |
| Fuel Tank Pressure Sensor Included | No |
| Universal Or Specific Fit | Specific |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8413309000 |
| Country of Origin (Primary) | TH |
| Harmonized Tariff Code (HTS) | 8413309030 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| UPC | 00689604207574 |
| VMRS Code | 044003258 |
| UNSPSC | 25172409 |
DELPHI FG0880 Cross References
| Brand | Part Number |
|---|---|
| Airtex | E2469M, E2457M |
| AutoZone | DFG0880 |
| Bosch | 66062, 66063, 69171 |
| CARTER FUEL PUMPS | P76341M, P76342M |
| Carquest | M2496134 |
| Carter | P76341M, P76342M |
| EVO Driveline | AFS0902S, RE0902S |
| Ford | 5R3Z 9H307-AC, 6R3Z 9H307-AA, 7R3Z 9H307-C |
| GMB | 525-2740 |
| Motorcraft | PFS-376, PFS-401 |
| N/A | 5R3Z9H307AC, 6R3Z9H307AA, 7R3Z9H307C, PFS376, USEP2457M, F1470A, C0096M, C0105M, SP2397M, 4010500, 4010583 |
| Precision Fuel | A33019 |
| SPECTRA PREMIUM | SP2397M |
| Spectra Premium | SP2099M, SP2062M, SP2137M |
| TYC | 150272-A |
DELPHI FG0880 Fits Vehicles
- Ford Mustang (2005-2009)
