(888) 312-8812 Login SignupDELPHI FG0829 Fuel Pump Module Assembly
MSRP: $557.19
$23449
Save $322.70
Limited availability at this price!
In Stock
Get it by Monday, Feb 16
DELPHI FG0829 Part Description
Manufacturer
Product Description
Fuel Pump Module Assembly
Features & Benefits
- Delphi is a global OE manufacturer and all fuel pumps are built to Delphi's OE standards
- Empty float height and float retention matches OE specifications and guarantees correct gas gauge reading
- Lower amperage draws less load on vehicle's electrical system
- Part is validated, tested and matched to the right vehicle application
- Always be sure to check and clean fuel tank to avoid unnecessary returns
- Lower failure rates due to its innovative design and durability
DELPHI FG0829 Specifications
Product Attributes
| Vapor Pressure Sensor | No |
| Package Contents | Fuel Pump Module Assembly w/Float Arm, Seal, Instruction Sheet |
| Item Grade | Standard Replacement |
| System Pressure | 51 psi |
| Fuel Level Sender Assembly Included | Yes |
| Outlet Outside Diameter | 0.375 IN |
| Voltage | 12 2H |
| Fuel Type | Gas |
| Regulator Included | No |
| Maximum Pressure | 78 PS |
| Terminal Type | Pin |
| Gasket Or Seal Included | Yes |
| Terminal Quantity | 8 |
| Lock Ring Included | No |
| Terminal Gender | Male |
| Strainer Included | Yes |
| Inlet Type | Strainer |
| Outlet Type | Quick Connect |
| Outlet Quantity | 1 |
| In Tank or External | In Tank |
| Resistance Ohms Empty | 15 82 |
| Resistance Ohms Full | 160 82 |
| Internal Or External Strainer | Internal |
| Pump Type | Electric |
| Average Current Draw | 14 68 |
| Average Flow Rating | 19 GPH |
| Fuel Sending Unit Included | Yes |
| Negative Ground | No |
| Mounting Hardware Included | No |
| Grade Type | Premium |
| Connector Quantity | 2 |
| Connector Shape | Round |
| Housing Material | Plastic |
| Installation Warnings | No |
| Connector Gender | Female |
| Fuel Filter Included | No |
| Gasket Or Seal Material | Nitrile Rubber |
| Minimum Pressure | 51 PS |
| Wire Harness Included | No |
| Pump Design | Turbine |
| Fuel Tank Pressure Sensor Included | No |
| Universal Or Specific Fit | Specific |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8413309000 |
| Harmonized Tariff Code (HTS) | 8413309030 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| Country of Origin (Primary) | TH |
| UPC | 00689604200964 |
| VMRS Code | 044003258 |
| UNSPSC | 25172409 |
DELPHI FG0829 Cross References
| Brand | Part Number |
|---|---|
| AUTOBEST | F1394A |
| Airtex | E2383M, E2386 |
| AutoZone | CFG0829 |
| Bosch | 69152 |
| CARTER FUEL PUMPS | P76041M, P76121M |
| Carter | P76041M, P76121M |
| DENSO Auto Parts | 953-4027 |
| EVO Driveline | AFS0886S, RE0886S |
| Ford | 3F2Z 9H307-AB, 3F2Z 9H307-A |
| GMB | 525-2625 |
| Motorcraft | PFS-21 |
| N/A | 9534027, 3F2Z9H307AB, PFS21, USEP2383M, C0076M, A27084, 4010424 |
| Precision Fuel | A30107 |
| Spectra Premium | SP2383M, SP1150 |
| Walbro | TU242 |
DELPHI FG0829 Fits Vehicles
- Mercury Monterey (2004-2005)
- Ford Freestar (2004-2005)
