(888) 312-8812 Login SignupDELPHI FG0411 Fuel Pump Module Assembly
$34699
Limited availability at this price!
In Stock
Get it by Friday, Aug 28
DELPHI FG0411 Part Description
Manufacturer
Product Description
Fuel Pump Module Assembly
Features & Benefits
- Delphi is a global OE manufacturer and all fuel pumps are built to Delphi's OE standards
- Empty float height and float retention matches OE specifications and guarantees correct gas gauge reading
- Lower amperage draws less load on vehicle's electrical system
- Part is validated, tested and matched to the right vehicle application
- Always be sure to check and clean fuel tank to avoid unnecessary returns
- Lower failure rates due to its innovative design and durability
DELPHI FG0411 Specifications
Product Attributes
| Vapor Pressure Sensor | No |
| Item Grade | Standard Replacement |
| System Pressure | 59 psi |
| Fuel Level Sender Assembly Included | Yes |
| Package Contents | Fuel Pump Module Assembly w/Float Arm, Seal, Instruction Sheet |
| Outlet Outside Diameter | 0.375 IN |
| Voltage | 12 2H |
| Fuel Type | Gas |
| Regulator Included | No |
| Maximum Pressure | 109 PS |
| Terminal Type | Blade |
| Gasket Or Seal Included | Yes |
| Terminal Quantity | 4 |
| Lock Ring Included | No |
| Terminal Gender | Male |
| Strainer Included | Yes |
| Inlet Type | Strainer |
| Outlet Type | Quick Connect |
| Outlet Quantity | 2 |
| In Tank or External | In Tank |
| Resistance Ohms Empty | 40 82 |
| Resistance Ohms Full | 250 82 |
| Internal Or External Strainer | Internal |
| Pump Type | Electric |
| Average Current Draw | 7 68 |
| Average Flow Rating | 30 GPH |
| Fuel Sending Unit Included | Yes |
| Negative Ground | No |
| Mounting Hardware Included | No |
| Wire Quantity | 4 |
| Grade Type | Premium |
| Connector Quantity | 1 |
| Connector Shape | Oval |
| Housing Material | Plastic |
| Installation Warnings | No |
| Connector Gender | Female |
| Fuel Filter Included | No |
| Gasket Or Seal Material | Nitrile Rubber |
| Minimum Pressure | 59 PS |
| Wire Harness Included | Yes |
| Pump Design | Turbine |
| Fuel Tank Pressure Sensor Included | Yes |
| Universal Or Specific Fit | Specific |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8413309000 |
| Country of Origin (Primary) | TH |
| Harmonized Tariff Code (HTS) | 8413309030 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| UPC | 00689604164006 |
| VMRS Code | 044003258 |
| UNSPSC | 25172409 |
DELPHI FG0411 Cross References
| Brand | Part Number |
|---|---|
| ACDelco | MU1356, MU1377, MU1835 |
| AUTOBEST | F2550A |
| Airtex | E3550M, E3549M |
| AutoZone | CFG0411 |
| Bosch | 67469, 67558, 67415 |
| CARTER FUEL PUMPS | P75053M |
| Carquest | M2510465 |
| Carter | P75053M |
| DENSO | 953-5134 |
| DENSO Auto Parts | 953-5134 |
| DORMAN | 2630353 |
| EVO Driveline | AFS0893S, RE0893S |
| GMB | 530-2110 |
| General Motors | 88966950, 88966952, 15050444 |
| Import Direct | A33014 |
| Isuzu | 8-15050-444-0 |
| Magneti Marelli | 1AMFP00102 |
| MasterPro Fuel Pumps | MPA33014 |
| N/A | 8150504440, 9535134, USEP3549M, F2550A, 4010345 |
| Precision Fuel | A33014 |
| Spectra Premium | SP3550M |
| TYC | 150093-A |
| URO | GM0516860 |
DELPHI FG0411 Fits Vehicles
- Chevrolet Trailblazer EXT (2002-2004)
- GMC Envoy XL (2002-2004)
- GMC Envoy XUV (2004)
- Chevrolet SSR (2003-2004)
- Isuzu Ascender (2003-2004)
