(888) 312-8812 Login SignupDELPHI FG0219 Fuel Pump Module Assembly
$22299
Limited availability at this price!
In Stock
Get as soon as Monday, Sep 21
DELPHI FG0219 Part Description
Manufacturer
Product Description
Fuel Pump Module Assembly
Features & Benefits
- Delphi is a global OE manufacturer and all fuel pumps are built to Delphi's OE standards
- Empty float height and float retention matches OE specifications and guarantees correct gas gauge reading
- Lower amperage draws less load on vehicle's electrical system
- Part is validated, tested and matched to the right vehicle application
- Always be sure to check and clean fuel tank to avoid unnecessary returns
- Lower failure rates due to its innovative design and durability
DELPHI FG0219 Specifications
Product Attributes
| System Pressure | 40 psi |
| Fuel Level Sender Assembly Included | Yes |
| Vapor Pressure Sensor | No |
| Package Contents | Fuel Pump Module Assembly w/Float Arm, Seal, Instruction Sheet |
| Item Grade | Standard Replacement |
| Outlet Outside Diameter | 0.375 IN |
| Voltage | 13 2H |
| Fuel Type | Gas |
| Regulator Included | Yes |
| Maximum Pressure | 45 PS |
| Terminal Type | Pin |
| Gasket Or Seal Included | Yes |
| Terminal Quantity | 5 |
| Lock Ring Included | No |
| Terminal Gender | Male |
| Strainer Included | Yes |
| Inlet Type | Strainer |
| Outlet Type | Quick Connect |
| Outlet Quantity | 2 |
| In Tank or External | In Tank |
| Resistance Ohms Empty | 102 82 |
| Resistance Ohms Full | 5 82 |
| Internal Or External Strainer | External |
| Pump Type | Electric |
| Average Current Draw | 7 68 |
| Average Flow Rating | 44 GPH |
| Fuel Sending Unit Included | Yes |
| Negative Ground | No |
| Mounting Hardware Included | No |
| Grade Type | Premium |
| Connector Quantity | 1 |
| Connector Shape | Oval |
| Housing Material | Plastic |
| Installation Warnings | No |
| Connector Gender | Female |
| Fuel Filter Included | Yes |
| Gasket Or Seal Material | Nitrile Rubber |
| Minimum Pressure | 40 PS |
| Wire Harness Included | No |
| Pump Design | Turbine |
| Fuel Tank Pressure Sensor Included | No |
| Universal Or Specific Fit | Specific |
Additional Information
| Harmonized Tariff Code (HTS) | 8413309030 |
| Warranty Special | Limited |
| Warranty Special UOM | LT |
| Harmonized Tariff Code (Schedule B) | 8413309000 |
| Country of Origin (Primary) | TH |
| UPC | 00689604061565 |
| VMRS Code | 044003258 |
| UNSPSC | 25172409 |
DELPHI FG0219 Cross References
| Brand | Part Number |
|---|---|
| ACDelco | PMU161 |
| AUTOBEST | F3076A |
| Airtex | E7065M |
| AutoZone | DFG0219 |
| Bosch | 67623, 67636 |
| CARTER FUEL PUMPS | P74673M |
| Carter | P74673M, P74695M |
| Chrysler | 52127747, 52127748, 4798 057, 4798 287 |
| DENSO | 953-3065 |
| DENSO Auto Parts | 953-3009, 953-3065, 953-6005 |
| DORMAN | 2630341 |
| EVO Driveline | AFS0284S, RE0284S |
| GMB | 520-2750 |
| Hella | H75030131 |
| Kem | EFP120M |
| N/A | 9533009, 9536005, 4798057, 4798287, USEP7065M, F3076A, 402-P7065M, C0413M, 4010045 |
| Precision Fuel | A30066 |
| Spectra Premium | SP6161M |
| URO | DG0517290 |
| Walbro | TU120 |
DELPHI FG0219 Fits Vehicles
- Dodge Ram 3500 (1994)
- Dodge Ram 2500 (1994)
- Dodge Ram 1500 (1994)
