Weatherhead H14510-250R - Eaton Weatherhead H145 Series Rubber Hydraulic Braided Hose
- Part Number
- H14510-250R
- Manufacturer
- WEATHERHEAD
- Description
-
Eaton Weatherhead H145 Series Rubber Hydraulic Braided Hose
details
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
Sometimes we may have similar parts for sale, click the button below to see if anything matches.
WEATHERHEAD part description
| Abrasion Resistance | Standard |
| Application | Construction. |
| Bend Radius Min | 4 inch |
| Burst Pressure | 12180 psi |
| Color | Black |
| Construction | 2-ply braid |
| Cover Material | Neoprene |
| Dash Size | -10 |
| Factory Crimp | Yes |
| Impulse Cycle Life | 200000 cycle |
| InsIDe Diameter | 0.625 inch |
| Lay Line Style | Ink Jet |
| Length Configuration | 50, 250 |
| OutsIDe Diameter | 0.97 inch |
| Package Form | Reel |
| Qualified Hose Fittings | U, Z |
| Reinforcement Material | Wire |
| Tube Material | Nitrile |
| Tube Wall Thickness | 0.17185 inch |
| Working Pressure | 3045 psi |
| Working Temperature Max | 250 degree Fahrenheit |
| Working Temperature Min | -40 degree Fahrenheit |
Features & Benefits
- Maximum durability under harsh operating conditions
- Robust construction able to withstand highest pressures
- System engineered to extend hose assembly life
Officially acquired by Eaton in 2002, Weatherhead® is one of the industry’s biggest suppliers of hydraulic hose, hose ends, tube fittings, couplings, assembly equipment, and support accessories. Weatherhead crafts top-products that are widely used in mining, agriculture, construction, truck, and bus applications. Eaton delivers Weatherhead thermoplastic tubing in different sizes—from 1/8 to 1 inch—designed for use in air tools, robotics, beverage dispensing as well as air and water supply. Driven by the company’s goal to offer unique solutions to a wide range of markets that enable businesses to be at the forefront of change, Weatherhead remains the truck industry’s leading source of premium-quality hoses, fittings, and adapters for your fleet’s hose and fittings needs
