WEATHERHEAD part description

Abrasion Resistance Premium
Application Hydraulics, air and lubricating oil.
Bend Radius Min 6.5 inch
Burst Pressure 6000 psi
Color Black
Conditional Temperature Range Hydraulic: -40 C to 100 C [-40 F to 212 F]; Air Brake: -40 C to 93 C [-40 F to 200 F]; Hot Oil: -40 C to 121 C [-40 F to 250 F];
Conductivity Conductive
Construction 3 Braid
Cover Material Polyester
Dash Size -12
Factory Crimp Yes
Impulse Cycle Life 150000 cycle
InsIDe Diameter 0.63 inch
Lay Line Style Ink Jet
Length Configuration 50, 250
OutsIDe Diameter 1.08 inch
Package Form Box
Qualified Hose Fittings 069 E, 247 N, 069 D
Reinforcement Material Polyester and Wire
Tube Material Nitrile
Tube Wall Thickness 0.45 inch
Working Pressure 1500 psi
Working Temperature Max 200 degree Fahrenheit
Working Temperature Min -40 degree Fahrenheit

Features & Benefits

  • Highly abrasion resistant cover
  • Small number of hoses for many fuel options
  • Proven reliability with high temperature resistance

WEATHERHEAD H06912 Cross Reference

We have 1 alternatives for the H06912 by WEATHERHEAD:

Officially acquired by Eaton in 2002, Weatherhead® is one of the industry’s biggest suppliers of hydraulic hose, hose ends, tube fittings, couplings, assembly equipment, and support accessories. Weatherhead crafts top-products that are widely used in mining, agriculture, construction, truck, and bus applications. Eaton delivers Weatherhead thermoplastic tubing in different sizes—from 1/8 to 1 inch—designed for use in air tools, robotics, beverage dispensing as well as air and water supply. Driven by the company’s goal to offer unique solutions to a wide range of markets that enable businesses to be at the forefront of change, Weatherhead remains the truck industry’s leading source of premium-quality hoses, fittings, and adapters for your fleet’s hose and fittings needs
