NGK Spark Plugs UR5 - NGK V-Power Spark Plug

Part Number
UR5
Manufacturer
NGK SPARK PLUGS
Description

NGK V-Power Spark Plug

details

NO STOCK AVAILABLE

We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.

Sometimes we may have similar parts for sale, click the button below to see if anything matches.

Search Alternatives

NGK SPARK PLUGS part description

Product Description

NGK V-Power Spark Plug

Features & Benefits

  • ACTUAL OE or EQUIVALENT DESIGN: OEM quality construction nickel alloy center electrode with V-groove provides consistent performance
  • RECOMMENDED USAGE: Best for vehicles with OE nickel alloy plugs, not recommended on vehicles with factory precious metal plugs
  • NGK's OE CERAMIC TECHNOLOGY: High grade alumina silicate ceramic creates a stronger insulator for optimal dielectric performance
  • SOLID COPPER CORE: 98% pure copper core offers superior heat dissipation, conductivity and ultra wide heat ranges
  • COLD-ROLLED THREADS: Prevents cross-threading and damage to cylinder heads
  • TRIVALENT METAL PLATING: Delivers superior anti-corrosion and anti-seizing properties, ensuring ease of installation and removal

Product Attributes

Short Style Spark Plug No
Service Number UR5
Stock Number 2771
Part Number UR5
Resistance 5000.0 82
Ground Electrode Tip Design Standard
Ground Configuration J-Gap
Ground Electrode Core Material Nickel
Washer Included No
Grade Type Regular
Electrical Terminal Type Non-Removable Nut
Center Electrode Core Material Copper
Center Electrode Tip Material Nickel
Pre-Gap Size .040 IN
Ground Electrode Quantity 1
Hex Size 5/8" (16mm)
Insulator Height 2.07 IN
Manufacturer Heat Range 5
Seat Type Tapered
Reach 0.460 IN
Thread Diameter 0.551 IN
Insulator Material Ceramic
Resistor Type Yes
6648 0.0 IN
Ground Electrode Tip Material Nickel
9459 No
9506 0.16 IN
9608 Standard
9805 Mid Projection

Additional Information

Harmonized Tariff Code (HTS) 8511100000
Warranty Time UOM MO
Warranty Time 2
Country of Origin (Primary) JP
UPC 00087295127711
VMRS Code 033003005
UNSPSC 26101732

Part Interchanges

Fits Vehicles

  • Ford F-250 HD (1997)
  • GMC C3500HD (1991-1995)
  • Chevrolet C3500HD (1991-1995)
  • Chevrolet P40 (1988)
  • Ford C600 (1986)
  • Ford B-600 (1986-1989)
  • Ford C700 (1986)
  • Ford B-700 (1986-1989)
  • Ford C800 (1986)
  • Mercury Cyclone (1971)
  • GMC Sprint (1971)
  • Ford Falcon (1970)
  • Dodge M350 (1974)
  • Dodge M300 (1974)
  • Chevrolet Biscayne (1971)
  • Chevrolet Bel Air (1971)
  • Pontiac Acadian (1976-1987)
  • Ford Thunderbird (1983)
  • Ford Mustang (1983)
  • Ford F-350 (1975, 1980, 1984-1997)
  • Ford F-250 (1980-1996)
  • Ford F-150 (1975, 1980-1996)
  • Ford F-100 (1975, 1980-1983)
  • Ford F-Super Duty (1997)
  • Ford E-350 Econoline Club Wagon (1985-1996)
  • Ford E-350 Econoline (1975, 1980-1982, 1985-1996)
  • Ford E-250 Econoline Club Wagon (1980, 1985-1991)
  • Ford E-250 Econoline (1975, 1980-1996)
  • Ford E-150 Econoline Club Wagon (1980-1996)
  • Ford E-150 Econoline (1975, 1980-1996)
  • Ford E-100 Econoline Club Wagon (1980-1982)
  • Ford E-100 Econoline (1975, 1980-1982)
  • Ford Econoline Super Duty (1996)
  • Ford Bronco (1975, 1980-1996)
  • Oldsmobile Custom Cruiser (1992)
  • Pontiac Trans Sport (1990-1995)
  • Pontiac T1000 (1981-1987)
  • Pontiac Sunbird (1976-1977, 1986)
  • Pontiac Parisienne (1986)
  • Pontiac Phoenix (1980-1984)
  • Pontiac J2000 (1982-1983)
  • Pontiac J2000 Sunbird (1984-1985)
  • Pontiac Grand Prix (1986)
  • Pontiac Firebird (1982-1995)
  • Pontiac Fiero (1985-1988)
  • Pontiac Bonneville (1986)
  • Pontiac Astre (1976-1977)
  • Pontiac 6000 (1982-1986)
  • Oldsmobile Starfire (1976-1977)
  • Oldsmobile Silhouette (1990-1994)
  • Oldsmobile Omega (1980-1984)
  • Oldsmobile Firenza (1982-1986)
  • Oldsmobile Cutlass Ciera (1982-1986)
  • Oldsmobile Bravada (1991-1994)
  • GMC Yukon (1992-1995)
  • GMC V2500 (1987)
  • GMC V3500 (1987-1991)
  • GMC V2500 Suburban (1987-1991)
  • GMC V1500 Suburban (1987-1991)
  • GMC V1500 (1987)
  • GMC Syclone (1991)
  • GMC Typhoon (1992-1993)
  • GMC Safari (1985-1995)
  • GMC Sonoma (1991-1995)
  • GMC S15 (1982-1990)
  • GMC S15 Jimmy (1983-1991)
  • GMC R3500 (1987-1991)
  • GMC R2500 Suburban (1987-1991)
  • GMC R2500 (1987-1989)
  • GMC R1500 Suburban (1987-1991)
  • GMC R1500 (1987)
  • GMC P3500 (1987-1997)
  • GMC P35 (1976)
  • GMC P2500 (1988-1989)
  • GMC P25 (1976)
  • GMC K3500 (1988-1995)
  • GMC K2500 Suburban (1992-1995)
  • GMC K2500 (1985-1986, 1988-1995)
  • GMC K1500 Suburban (1985-1986, 1992-1995)
  • GMC K1500 (1985-1986, 1988-1995)
  • GMC Jimmy (1984-1995)
  • GMC G3500 (1984-1996)
  • GMC G2500 (1984-1995)
  • GMC G1500 (1984-1995)
  • GMC Caballero (1986)
  • GMC C3500 (1988-1995)
  • GMC C2500 Suburban (1985-1986, 1992-1995)
  • GMC C2500 (1985-1986, 1988-1995)
  • GMC C1500 Suburban (1985-1986, 1992-1995)
  • GMC C1500 (1984-1986, 1988-1995)
  • Chevrolet Vega (1971-1974, 1976-1977)
  • Chevrolet V3500 (1989-1991)
  • Chevrolet V20 (1987)
  • Chevrolet V30 (1987-1988)
  • Chevrolet V2500 Suburban (1989-1991)
  • Chevrolet V20 Suburban (1987-1988)
  • Chevrolet V1500 Suburban (1989-1991)
  • Chevrolet V10 Suburban (1987-1988)
  • Chevrolet V10 (1987)
  • Chevrolet Tahoe (1995)
  • Chevrolet S10 (1982-1995)
  • Chevrolet S10 Blazer (1983-1994)
  • Chevrolet R3500 (1989-1991)
  • Chevrolet R30 (1987-1988)
  • Chevrolet R2500 Suburban (1989-1991)
  • Chevrolet R2500 (1989)
  • Chevrolet R20 Suburban (1987-1988)
  • Chevrolet R1500 Suburban (1989-1991)
  • Chevrolet R20 (1987-1988)
  • Chevrolet R10 Suburban (1987-1988)
  • Chevrolet R10 (1987)
  • Chevrolet P30 (1987-1997)
  • Chevrolet P20 (1987-1989)
  • Chevrolet Monza (1976-1977)
  • Chevrolet Monte Carlo (1971, 1985-1986)
  • Chevrolet Lumina APV (1990-1995)
  • Chevrolet K30 (1985)
  • Chevrolet K3500 (1988-1995)
  • Chevrolet K2500 Suburban (1992-1995)
  • Chevrolet K2500 (1988-1995)
  • Chevrolet K20 Suburban (1984-1986)
  • Chevrolet K20 (1985-1986)
  • Chevrolet K1500 Suburban (1992-1995)
  • Chevrolet K1500 (1988-1995)
  • Chevrolet K10 Suburban (1984-1986)
  • Chevrolet K10 (1985-1986)
  • Chevrolet G30 (1984-1996)
  • Chevrolet G20 (1984-1995)
  • Chevrolet G10 (1984-1995)
  • Chevrolet El Camino (1971, 1986)
  • Chevrolet Corvette (1971, 1985-1987)
  • Chevrolet Citation II (1984-1985)
  • Chevrolet Citation (1980-1983)
  • Chevrolet Chevette (1976-1987)
  • Chevrolet Celebrity (1982-1986)
  • Chevrolet Cavalier (1982-1986)
  • Chevrolet Caprice (1971, 1989-1993)
  • Chevrolet Camaro (1982-1995)
  • Chevrolet C3500 (1988-1995)
  • Chevrolet C2500 Suburban (1992-1995)
  • Chevrolet C2500 (1988-1995)
  • Chevrolet C20 Suburban (1984-1986)
  • Chevrolet C20 (1985-1986)
  • Chevrolet C1500 Suburban (1992-1995)
  • Chevrolet C1500 (1988-1995)
  • Chevrolet C10 Suburban (1984-1986)
  • Chevrolet C10 (1984-1986)
  • Chevrolet K5 Blazer (1984-1986)
  • Chevrolet Blazer (1987-1995)
  • Chevrolet Astro (1985-1995)
  • Cadillac Commercial Chassis (1992)
  • Cadillac Brougham (1990-1992)
  • Cadillac Cimarron (1982-1986)
  • Buick Skylark (1980-1985)
  • Buick Skyhawk (1982-1986)
  • Buick Commercial Chassis (1992-1993)
  • Buick Roadmaster (1992-1993)
  • Buick Century (1983-1986)
  • AM General Hummer (1995-1996)
  • Jeep Wagoneer (1984-1986)
  • Jeep Comanche (1986)
  • Jeep Cherokee (1984-1986)
  • Isuzu Trooper (1989-1991)
  • Isuzu Rodeo (1991-1992)
  • Isuzu Pickup (1991-1994)
