(888) 312-8812 Login SignupWAGNER ZD580 QuickStop Ceramic Disc Brake Pad Set
Tap to view 2 more
MSRP: $52.01
$3749
Save $14.52
Limited availability at this price!
In Stock
Get it by Friday, Jul 24
WAGNER ZD580 Part Description
Manufacturer
Features & Benefits
- RESTORES LIKE-NEW BRAKING PERFORMANCE -- OE fit and form design delivers consistent, even braking throughout the life of the brake pad
- REDUCED VIBRATION -- Application-specific design reduces noise-causing vibration
- VEHICLE-SPECIFIC MATERIALS -- Formulated to meet the unique needs of each vehicle application
- HARDWARE INCLUDED -- Premium stainless-steel hardware included in most applications
- COMPREHENSIVE COVERAGE -- Brake pads available for all vehicle types
- ZERO COPPER FORMULATION -- Features Wagner OE25™ zero-copper friction formulation
- QUIETER OPERATION -- Up to four-layer shim (application specific) helps dampen vibration and reduce squeal for smoother, quieter braking performance
- PAD LIFE MONITORING -- Application-specific brake wear sensor detects pad wear and provides a timely alert to support proactive maintenance and preserve braking performance
- BUILT TO STAY PUT -- Thermoset adhesive secures the friction material to the backplate, maintaining bond integrity through heat, pressure and repeated stops
- CORROSION PROTECTION -- Powder-coated backplate helps resist rust and extend product life
- LAB-TESTED PERFORMANCE -- Validated on a dynamometer using SAE J2521 (noise), SAE J2522 (effectiveness) and Los Angeles City Traffic protocols to ensure quiet operation, consistent stopping power and pad life
- PERFECT PAIRING -- Pair Wagner® Standard brake pads with Wagner rotors and calipers (sold separately) for optimal performance
- PERFECT PAIRING -- Pair Wagner(R) Standard brake pads with Wagner rotors and calipers (sold separately) for optimal performance
Rely on the Wagner® Brake QuickStop® disc brake pad set to restore like-new braking performance to your vehicle.
Wagner® QuickStop® ceramic brake pads are designed, tested and certified to ensure a vehicle's braking system will be restored to original equipment performance.
- Optimal stopping performance
- Application-specific design reduces noise-causing vibration
- 100% OE-post cured for consistent braking throughout the life of the pad
- Includes OE-style lubricant
- Low copper 2021 compliant ceramic formulation
- Install Wagner with total confidence
Part Specifications
BRAKE PADS
| Pad FMSI Number | 7460-D580 |
| Abutement Hardware Included | Yes |
| Friction Thickness Inner Pad (Inch) | 0.622 |
| Friction Thickness Outer Pad (Inch) | 0.622 |
| Front or Rear Pads | Rear |
| OEM Replacement | Yes |
| Package Quantity | 4 |
| Pad Material | Ceramic |
| Shims Included | Yes |
| Wear Sensors Included | Mechanical |
| Performance | No |
WAGNER ZD580 Specifications
Product Attributes
| Friction Material Composition | Ceramic |
| FMSI Number | 7460-D580 |
| Abutment Clips Included | Yes |
| Pad Shims Included | Yes |
| Chamfered Edges | No |
| Slotted | No |
| Inner Pad Friction Material Thickness | 0.622 IN |
| Outer Pad Friction Material Thickness | 0.622 IN |
| Pad Wear Sensor Included | Yes |
| Pad Wear Sensor Type | Mechanical |
| Part Description | Disc Brake Pad Set |
| FMSI Lining | 7460 |
| Fmsi Steel | D580 |
Additional Information
| MSDS Sheet Number | 5008 |
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 8708305020 |
| Harmonized Tariff Code (HTS) | 8708305020 |
| UPC | 00008536321927 |
| VMRS Code | 013000000 |
| UNSPSC | 25171713 |
WAGNER ZD580 Cross References
| Brand | Part Number |
|---|---|
| 102.05800 | |
| Akebono ProACT | ACT580 |
| Auto Extra | AXCD580, AXOD580 |
| BRAKE PRO | BKP580CH |
| Bendix | D580, SBC580, SCD580, D580CT, RD580 |
| Bosch | BC580, BE580, BE580H, BP580 |
| BrakeBest Select Brake Pads | D580, SC580 |
| CENTRIC | 301.05800 |
| Carquest | BD580, BD580A |
| Carquest Premium Gold | GNAD580 |
| Carquest Professional Platinum Brake Pads | PXD580H |
| Carquest Standard Brake Pads | NAD580 |
| Centric Parts | 301.05800, 102.05800, 103.05800, 105.05800, 300.05800, 308.05800 |
| Detroit Axle | P580 |
| Duralast | D580, DG580 |
| Dynamic Friction Company | 4000-0580-00, 1551-0580-00, 1901-0580-00, 1551-0580-01, 4000-0580-01, 1310-0580-00, 1310-0580-01, 1311-0580-01 |
| General Motors | 8970352660 |
| Honda | 8971317490 |
| Isuzu | 8970352662, 8970700800 |
| MAGMA PRODUCTS | PMD580C |
| Monroe Shocks & Struts | CX580, GX580 |
| Morse | NX580 |
| NAPA BRAKES | PF7460X, PF7586M, PF7586X, UP7460X, UP7460, SS7586, UP7586, SS7460X, SG7460X |
| Pep Boys | PD580, PGD580, PS580C, PD580C |
| PowerStop | 16580, 17580, Z23580 |
| RAYBESTOS | PGD580, ATD580C |
| Raybestos Brakes | PGD580C, MGD580CH, EHT580H, SGD580C, PGD580AC, MGD580ACH |
| VORTEX | VXD580CH |
WAGNER ZD580 Fits Vehicles
- Honda Passport (2000-2002)
- Acura SLX (1996-1999)
- Isuzu VehiCROSS (1999-2001)
- Isuzu Trooper (1992-2002)
- Isuzu Rodeo Sport (2001-2003)
- Isuzu Rodeo (1993-1995, 2001-2004)
- Isuzu Axiom (2002-2004)
- Isuzu Amigo (1994)
