CENTRIC 122.48010 Part Description
Manufacturer
Product Description
Centric Premium Brake Drum
Features & Benefits
- OE style castings ensure superior performance and extended service life. Machined finishes provide cleaner appearance through wheels. Precision machined friction surfaces ensure smooth operation and reduced noise
- For best operation and ultimate strength
- OE-Matched Fit, Form, and Function
- 100% Mill Balanced
- For vibration free performance
- Black Painted Exterior
- For corrosion resistance
CENTRIC 122.48010 Specifications
Product Attributes
| Misc Holes [cntrc] | 4 |
| Weight [cntrc] Kgs | 3.864 |
| Weight [cntrc] Lbs | 8.500 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 100.000 |
| Bolt Circle Diameter [cntrc] In | 3.937 |
| Hub Hole / Register [cntrc] Mm | 58.000 |
| Hub Hole / Register [cntrc] In | 2.283 |
| Height [cntrc] Mm | 56.400 |
| Height [cntrc] In | 2.220 |
| Friction Surface Width [cntrc] Mm | 39.900 |
| Friction Surface Width [cntrc] In | 1.571 |
| Product Grade [cntrc] | Premium |
| Maximum Brake Diameter (Discard) | 202.000 MM |
| Maximum Brake Diameter (Discard) | 7.953 IN |
| Bolt Hole Quantity | 4 |
| Outside Diameter | 245.000 MM |
| Outside Diameter | 9.646 IN |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 12.600 MM |
| Mounting Hole Diameter | 0.496 IN |
| Nominal Drum Diameter | 199.700 MM |
| Nominal Drum Diameter | 7.862 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890032663 |
CENTRIC 122.48010 Cross References
CENTRIC 122.48010 Fits Vehicles
- Suzuki Esteem (1995-2002)
- Suzuki Aerio (2002-2007)
