CENTRIC 122.61010 Part Description
Manufacturer
Product Description
Centric Premium Brake Drum
Features & Benefits
- OE style castings ensure superior performance and extended service life. Machined finishes provide cleaner appearance through wheels. Precision machined friction surfaces ensure smooth operation and reduced noise
- For best operation and ultimate strength
- OE-Matched Fit, Form, and Function
- 100% Mill Balanced
- For vibration free performance
- Black Painted Exterior
- For corrosion resistance
CENTRIC 122.61010 Specifications
Product Attributes
| Weight [cntrc] Kgs | 7.955 |
| Weight [cntrc] Lbs | 17.500 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 114.300 |
| Bolt Circle Diameter [cntrc] In | 4.500 |
| Hub Hole / Register [cntrc] Mm | 61.722 |
| Hub Hole / Register [cntrc] In | 2.430 |
| Height [cntrc] Mm | 96.774 |
| Height [cntrc] In | 3.810 |
| Friction Surface Width [cntrc] Mm | 71.374 |
| Friction Surface Width [cntrc] In | 2.810 |
| Product Grade [cntrc] | Premium |
| Maximum Brake Diameter (Discard) | 256.300 MM |
| Maximum Brake Diameter (Discard) | 10.090 IN |
| Bolt Hole Quantity | 5 |
| Outside Diameter | 314.960 MM |
| Outside Diameter | 12.400 IN |
| Outer Cooling Fins | Yes |
| Mounting Hole Diameter | 15.494 MM |
| Mounting Hole Diameter | 0.610 IN |
| Nominal Drum Diameter | 254.000 MM |
| Nominal Drum Diameter | 10.000 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890044987 |
CENTRIC 122.61010 Cross References
| Brand | Part Number |
|---|---|
| N/A | BD60108, E127-66-015, 87029, YH140010, 8831, 23036, 8831C, X21562, 8831CG, BD1010, C6OZ1125A, C7OZ1102A, C8OZ1125B, C9OZ1102B, D0OZ1102A, C3OZ1102A, C3OZ1102B, C3OZ1102D, D3ZZ1102A, 140010, PDR0010, 1634, 6401017, 883, 8834010, AD8110, D5634, 177218, 36554013, E12766015 |
| RAYBESTOS | 1634R |
| Raybestos Brakes | 1634R |
| WAGNER | BD60108 |
CENTRIC 122.61010 Fits Vehicles
- Mercury Villager (1963-1965, 1967)
- Mercury Voyager (1966-1967)
- Mercury Montego (1968-1971)
- Mercury Cyclone (1964-1971)
- Mercury Cougar (1967-1972)
- Mercury Comet (1963-1969, 1971-1973)
- Mercury Caliente (1964-1967)
- Ford Torino (1968-1971)
- Ford Ranchero (1963-1971)
- Ford Mustang (1964-1973)
- Ford Maverick (1971-1973)
- Ford Falcon Sedan Delivery (1965)
- Ford Falcon (1965-1970)
- Ford Fairlane (1962-1970)
- Ford Country Squire (1969-1970)
