(888) 312-8812 Login SignupCENTRIC 123.62007 C-Tek Standard Brake Drum
Tap to view 4 more
$12799
Limited availability at this price!
In Stock
Get it by Tuesday, Dec 30
CENTRIC 123.62007 Part Description
Manufacturer
Product Description
C-Tek Standard Brake Drum
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
CENTRIC 123.62007 Specifications
Product Attributes
| Weight [cntrc] Kgs | 8.977 |
| Weight [cntrc] Lbs | 19.750 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 120.650 |
| Bolt Circle Diameter [cntrc] In | 4.750 |
| Hub Hole / Register [cntrc] Mm | 70.612 |
| Hub Hole / Register [cntrc] In | 2.780 |
| Height [cntrc] Mm | 99.822 |
| Height [cntrc] In | 3.930 |
| Friction Surface Width [cntrc] Mm | 76.454 |
| Friction Surface Width [cntrc] In | 3.010 |
| Product Grade [cntrc] | Standard |
| Maximum Brake Diameter (Discard) | 243.600 MM |
| Maximum Brake Diameter (Discard) | 9.590 IN |
| Bolt Hole Quantity | 5 |
| Outside Diameter | 293.624 MM |
| Outside Diameter | 11.560 IN |
| Outer Cooling Fins | Yes |
| Mounting Hole Diameter | 13.462 MM |
| Mounting Hole Diameter | 0.530 IN |
| Nominal Drum Diameter | 241.300 MM |
| Nominal Drum Diameter | 9.500 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| UPC | 805890977780 |
CENTRIC 123.62007 Part Interchanges
| Brand | Part Number |
|---|---|
| N/A | BD60272, 8781, 123.62007, 8781C, 8781CG, 481832, 140206, PDR0206, 201810, 6401191, 916, AD8207, D5282, 87066, X21494, BD1176, 1282, 1282DGS, 8836007, 36552001, 177211 |
CENTRIC 123.62007 Fits Vehicles
- Pontiac Firebird (1969)
- Pontiac Tempest (1969-1970)
- Pontiac LeMans (1970-1972)
- Pontiac GTO (1969-1972)
- Pontiac Grand Prix (1969)
CENTRIC 123.62007 Cross References
We have 1 alternatives for the 123.62007 by CENTRIC:
