Centric 226.37054 - C-Tek Standard Slotted Brake Rotor
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
Sometimes we may have similar parts for sale, click the button below to see if anything matches.
CENTRIC part description
Product Description
C-Tek Standard Slotted Brake Rotor
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. G11 metallurgy. Slotted for increased bite; improved looks and better performance
Product Attributes
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Disc Mounting [cntrc] | Floating / DIH |
| Weight [cntrc] Kgs | 10.160 |
| Vane Style [cntrc] | Curved |
| Misc Holes [cntrc] | 2 |
| Weight [cntrc] Lbs | 22.350 |
| Product Grade [cntrc] | Standard |
| Discard Thickness | 26.000 MM |
| Discard Thickness | 1.024 IN |
| Nominal Thickness | 1.098 IN |
| Nominal Thickness | 27.900 MM |
| Overall Height | 75.200 MM |
| Overall Height | 2.961 IN |
| Outside Diameter | 350.000 MM |
| Outside Diameter | 13.780 IN |
| ABS Tone Ring Included | No |
| Surface Type | Slotted |
| Solid Or Vented Type Rotor | Vented |
| Nominal Drum Diameter | 180.000 MM |
| Nominal Drum Diameter | 7.087 IN |
| Bearings Included | No |
| Center Hole Diameter | 3.862 IN |
| Center Hole Diameter | 98.100 MM |
| Mounting Bolt Hole Circle Diameter | 130.000 MM |
| Mounting Bolt Hole Circle Diameter | 5.118 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 15.550 MM |
| Stud/Lug Hole Diameter | 0.612 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 805890402152 |
Part Interchanges
Fits Vehicles
- Porsche Panamera (2010-2016)
- Porsche 911 (2007-2013)
