CENTRIC 120.5001 Part Description
Manufacturer
Product Description
Centric Premium Brake Rotor
Application Summary
Hyundai Sonata 2005-2004, Kia Magentis 2005-2002, Optima 2006-2002
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
Premium rotor; rotors; Centric; brake rotor; break; brake disc; disc brake
CENTRIC 120.5001 Specifications
Product Attributes
| Discard Thickness | 24.400 MM |
| Nominal Thickness | 1.024 IN |
| Hat Finish | Coated |
| Overall Height | 1.870 IN |
| Outside Diameter | 280.000 MM |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 2.717 IN |
| Mounting Bolt Hole Circle Diameter | 114.300 MM |
| Stud/Lug Hole Quantity | 4 |
| Stud/Lug Hole Diameter | 0.490 IN |
| California Proposition 65 Text [basic] | WARNING: Cancer and Reproductive Harm |
| Disc Mounting [cntrc] | Floating |
| Misc Holes [cntrc] | 2 |
| Vane Style [cntrc] | Straight |
| Weight [cntrc] Kgs | 7.270 |
| Weight [cntrc] Lbs | 16.000 |
| Discard Thickness | 0.961 IN |
| Nominal Thickness | 26.000 MM |
| Mounting Bolt Hole Circle Diameter | 4.500 IN |
| Stud/Lug Hole Diameter | 12.450 MM |
| Disc Mounting | Floating |
| Misc Holes | 2 |
| Vane Style | Straight |
| Weight | 7.270 |
Additional Information
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| UPC | 00805890196051 |
CENTRIC 120.5001 Cross References
CENTRIC 120.5001 Fits Vehicles
- Kia Magentis (2002-2005)
- Hyundai Sonata (2004-2005)
- Kia Optima (2002-2006)
