CENTRIC 123.43000 Part Description
Manufacturer
Product Description
C-Tek Standard Brake Drum
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
- For best operation and ultimate strength
- OE-Matched Fit, Form, and Function
- 100% Mill Balanced
- For vibration free performance
- Meets SAE Standard for Tensile Strength
- For maximum service life and structural integrity
CENTRIC 123.43000 Specifications
Product Attributes
| Misc Holes [cntrc] | 1 |
| Weight [cntrc] Kgs | 6.477 |
| Weight [cntrc] Lbs | 14.250 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 139.700 |
| Bolt Circle Diameter [cntrc] In | 5.500 |
| Hub Hole / Register [cntrc] Mm | 96.500 |
| Hub Hole / Register [cntrc] In | 3.799 |
| Height [cntrc] Mm | 69.000 |
| Height [cntrc] In | 2.717 |
| Friction Surface Width [cntrc] Mm | 56.000 |
| Friction Surface Width [cntrc] In | 2.205 |
| Product Grade [cntrc] | Standard |
| Maximum Brake Diameter (Discard) | 255.500 MM |
| Maximum Brake Diameter (Discard) | 10.060 IN |
| Bolt Hole Quantity | 6 |
| Outside Diameter | 293.500 MM |
| Outside Diameter | 11.555 IN |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 12.500 MM |
| Mounting Hole Diameter | 0.492 IN |
| Nominal Drum Diameter | 254.000 MM |
| Nominal Drum Diameter | 10.000 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| UPC | 00805890914686 |
CENTRIC 123.43000 Cross References
| Brand | Part Number |
|---|---|
| N/A | 0831999, E127-48-005, E128-48-005, 3557, BR3557, BD3557, 123.43000, 63 73 150, 6373150, 3557G, 664, 5423150010, 5423150011, 5423150020, 5423150100, 5423150291, 5423150311, 94020624, 94021318, 94022831, 94022832, 94023920, 94029151, 9423156260, 9423156280, 140357, 140471, 201570, 6401503, 989, JBD127, D9106, E12748005, 100553, 87195, 21046, X21659, BD1150, 9106, 9106R, 9106DGS, 36547000 |
| PRONTO | BD3517 |
| RAYBESTOS | 9106, 9106R |
CENTRIC 123.43000 Fits Vehicles
- Chevrolet Luv Pickup (1972-1974)
- Chevrolet LUV (1975-1980)
