(888) 312-8812 Login SignupCENTRIC 121.65020 C-Tek Standard Brake Rotor
Tap to view 4 more
$100.24
MSRP Pricing shown.
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
CENTRIC 121.65020 Part Description
Manufacturer
Product Description
C-Tek Standard Brake Rotor
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
- For heat capacity and strength
- OE Vane Design & Plate Thickness
- Optimal Surface Finish
- For consistent stopping power
- Low Initial Lateral Run-Out and Disc-Thickness Variation
- For smooth, vibration free stopping
- Precision Balanced
- For vibration free performance
CENTRIC 121.65020 Specifications
Product Attributes
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Misc Holes [cntrc] | 0 |
| Product Grade [cntrc] | Standard |
| Disc Mounting [cntrc] | Behind the Hub |
| Weight [cntrc] Kgs | 15.450 |
| Vane Style [cntrc] | Straight |
| Weight [cntrc] Lbs | 34.000 |
| Discard Thickness | 1.429 IN |
| Discard Thickness | 36.300 MM |
| Nominal Thickness | 1.504 IN |
| Nominal Thickness | 38.200 MM |
| Overall Height | 124.000 MM |
| Overall Height | 4.882 IN |
| Outside Diameter | 327.700 MM |
| Outside Diameter | 12.902 IN |
| Mounting Bolt Hole Quantity | 10 |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 123.300 MM |
| Center Hole Diameter | 4.854 IN |
| Mounting Bolt Hole Circle Diameter | 144.800 MM |
| Mounting Bolt Hole Circle Diameter | 5.701 IN |
| Mounting Bolt Hole Diameter | 13.100 MM |
| Mounting Bolt Hole Diameter | 0.516 IN |
| Hat Finish | Bare |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890050438 |
CENTRIC 121.65020 Cross References
| Brand | Part Number |
|---|---|
| MAGMA PRODUCTS | PMR207275 |
| N/A | BD61833, 52-61833, 5261833, E126-70-025, 5459, BR5459, 5459G, 107191, F2TZ1113A, E8TZ1125A, 23106835, PRT1455, 141455, 102590, 86205, 588, AR8520E, D17485, E12670025, X50415, 27115, 66205, 66205R, 66205RGS, 1066205, 78-42020, 7842020, 78942020, 65645, 60054112 |
| PRONTO | BR5459 |
| RAYBESTOS | 66205, 66205R |
| WAGNER | BD61833 |
CENTRIC 121.65020 Fits Vehicles
- Ford F-59 Commercial Stripped Chassis (1988-1997)
- Ford F-53 Motorhome Chassis (1988-1997)
- Ford F-Super Duty (1988-1997)
