(888) 312-8812 Login SignupCENTRIC 120.45083 Centric Premium Brake Rotor
Tap to view 4 more
MSRP: $67.69
$4349
Save $24.20
Limited availability at this price!
In Stock
Get it by Wednesday, Jan 7
CENTRIC 120.45083 Part Description
Manufacturer
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
CENTRIC 120.45083 Specifications
Product Attributes
| Disc Mounting [cntrc] | Floating |
| Misc Holes [cntrc] | 1 |
| Hat Id [cntrc] In | 5.571 |
| Weight [cntrc] Lbs | 9.950 |
| Product Grade [cntrc] | Premium |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Hat Id [cntrc] Mm | 141.500 |
| Weight [cntrc] Kgs | 4.520 |
| Discard Thickness | 0.315 IN |
| Discard Thickness | 8.000 MM |
| Nominal Thickness | 0.394 IN |
| Nominal Thickness | 10.000 MM |
| Hat Finish | Coated |
| Overall Height | 1.559 IN |
| Overall Height | 39.600 MM |
| Outside Diameter | 302.400 MM |
| Outside Diameter | 11.906 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Solid |
| Bearings Included | No |
| Center Hole Diameter | 2.677 IN |
| Center Hole Diameter | 68.000 MM |
| Mounting Bolt Hole Circle Diameter | 114.300 MM |
| Mounting Bolt Hole Circle Diameter | 4.500 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 13.000 MM |
| Stud/Lug Hole Diameter | 0.512 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 805890861966 |
CENTRIC 120.45083 Part Interchanges
| Brand | Part Number |
|---|---|
| Raybestos Brakes | 981008FZN, 981008R |
| N/A | 120.45083, 850320, BD180544, BD180544E, BR90119602, 44771, 90080070, 77105, K01126251A, K01126251, K01126251B, 981008 |
CENTRIC 120.45083 Fits Vehicles
- Mazda CX-5 (2013-2023)
CENTRIC 120.45083 Cross References
We have 2 alternatives for the 120.45083 by CENTRIC:
