(888) 312-8812 Login SignupCENTRIC 130.46400 Centric Premium Brake Master Cylinder
*Representative image - actual part not displayed
$122.89
MSRP Pricing shown.
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
CENTRIC 130.46400 Part Description
Manufacturer
Product Description
Centric Premium Brake Master Cylinder
Features & Benefits
- Match O.E. parts in quality; configuration and fitment. Complete with reservoirs; switches and floats. Original aluminum casting body design where applicable. Manufactured under the highest quality standards by OEM and OES manufacturers
CENTRIC 130.46400 Specifications
Product Attributes
| Publication Bore [cntrc] | 11/16" |
| Push Rod: Length / Depth [cntrc] In | 0.963 |
| Boss, Nipple Or Port: Front, Left: #a [cntrc] | M10-1.00 inv |
| Boss, Nipple Or Port: Front, Right: #a [cntrc] | M7-1.00 bbl |
| Boss, Nipple Or Port: Rear: #a [cntrc] | M10-1.00 inv |
| Boss, Nipple Or Port: Rear, Right: #a [cntrc] | M7-1.00 bbl |
| Weight [cntrc] Lbs | 2.25 |
| Weight [cntrc] Kgs | 1.02 |
| Primary Outlet Flare Type [cntrc] | Inverted |
| Secondary Outlet Flare Type [cntrc] | Inverted |
| Product Grade [cntrc] | Premium |
| Reservoir Material | Plastic |
| Mounting Hardware Included | No |
| Mounting Hole Quantity | 2 |
| Master Cylinder Bore Diameter | 17.463 MM |
| Master Cylinder Bore Diameter | 0.688 IN |
| Bleeder Screw Included | Yes |
| Brake Booster Included | No |
| Master Cylinder Cap Included | Yes |
| Master Cylinder Material | Aluminum |
| Push Rod Included | No |
| Reservoir Included | Yes |
| Reservoir Type | Dual |
| Primary Outlet Thread Diameter | 10.000 MM |
| Secondary Outlet Thread Diameter | 10.000 MM |
| Bleeder Thread Diameter | 7.000 MM |
| Bleeder Hoses Included | No |
| Port Quantity | 2 |
| Mounting Bracket Included | No |
| Secondary Outlet Thread Pitch | 1.00 MM |
| Primary Outlet Thread Pitch | 1.00 MM |
| Bore Type | Straight |
| Bore Size | 17.463 MM |
| Bore Size | 0.688 IN |
| Secondary Outlet Thread Size | M10-1.00 |
| Primary Outlet Thread Size | M10-1.00 |
| Bleeder Screw Quantity | 2 |
| 9564 | 1.00 |
| Primary Outlet Flare Type | Inverted |
| Secondary Outlet Flare Type | Inverted |
| Primary Bore Diameter | 17.463 MM |
| Primary Bore Diameter | 0.688 IN |
| Reservoir Style | Removable |
Additional Information
| Harmonized Tariff Code (HTS) | 8413919050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890005360 |
CENTRIC 130.46400 Cross References
| Brand | Part Number |
|---|---|
| DORMAN | M39022 |
| N/A | 0720193, F100991, 230246400, 2302-46400, 6675010, M52400, CM1176, MA161841, MA161842, MA161874, 11713 |
CENTRIC 130.46400 Fits Vehicles
- Dodge Colt (1971-1972)
