(888) 312-8812 Login SignupCENTRIC 12137032 C-Tek Standard Brake Rotor
$72.24
MSRP Pricing shown.
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
CENTRIC 12137032 Part Description
Manufacturer
Product Description
C-Tek Standard Brake Rotor
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
- For heat capacity and strength
- OE Vane Design & Plate Thickness
- Optimal Surface Finish
- For consistent stopping power
- Low Initial Lateral Run-Out and Disc-Thickness Variation
- For smooth, vibration free stopping
- Precision Balanced
- For vibration free performance
CENTRIC 12137032 Specifications
Product Attributes
| Vane Style [cntrc] | Curved |
| Max Pb Drum Dia [cntrc] In | 7.126 |
| Product Grade [cntrc] | Standard |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Weight [cntrc] Kgs | 7.240 |
| Misc Holes [cntrc] | 3 |
| Weight [cntrc] Lbs | 15.930 |
| Disc Mounting [cntrc] | Floating / DIH |
| Max Pb Drum Dia [cntrc] Mm | 181.000 |
| Discard Thickness | 1.024 IN |
| Discard Thickness | 26.000 MM |
| Nominal Thickness | 27.940 MM |
| Nominal Thickness | 1.100 IN |
| Overall Height | 73.900 MM |
| Overall Height | 2.909 IN |
| Outside Diameter | 298.700 MM |
| Outside Diameter | 11.760 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Nominal Drum Diameter | 180.090 MM |
| Nominal Drum Diameter | 7.090 IN |
| Bearings Included | No |
| Center Hole Diameter | 103.000 MM |
| Center Hole Diameter | 4.055 IN |
| Mounting Bolt Hole Circle Diameter | 5.118 IN |
| Mounting Bolt Hole Circle Diameter | 130.000 MM |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 15.540 MM |
| Stud/Lug Hole Diameter | 0.612 IN |
| Hat Finish | Bare |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890402770 |
CENTRIC 12137032 Cross References
CENTRIC 12137032 Fits Vehicles
- Porsche 911 (1991-1994)
