CENTRIC 120.65136 Part Description
Manufacturer
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
- Painted hat and outer edge for corrosion resistance
- Symmetric vane; split-core castings for uniform heat distribution. Anti-corrosive paint protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life.
- Painted Hat and Outer Edge
- Optimal Surface Finish
- Optimal surface finish for consistent stopping feel from the first stop
- Advanced Metallurgy
- Advanced metallurgy for optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- OE vane design and plate thickness for heat capacity and strength
- Low Initial Lateral Run-Out
- Low initial lateral run-out and disc thickness variation for smooth, vibration free stopping
- Precision Balance
- Precision balance for vibration free performance
CENTRIC 120.65136 Specifications
Product Attributes
| Disc Mounting [cntrc] | Floating |
| Vane Style [cntrc] | Straight |
| Notes [cntrc] | Vented Hat |
| Hat Id [cntrc] Mm | 150.400 |
| Weight [cntrc] Kgs | 12.780 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Misc Holes [cntrc] | 1 |
| Hat Id [cntrc] In | 5.921 |
| Weight [cntrc] Lbs | 28.150 |
| Product Grade [cntrc] | Premium |
| Discard Thickness | 1.181 IN |
| Discard Thickness | 30.000 MM |
| Nominal Thickness | 32.000 MM |
| Nominal Thickness | 1.260 IN |
| Hat Finish | Painted |
| Overall Height | 1.854 IN |
| Overall Height | 47.100 MM |
| Outside Diameter | 352.000 MM |
| Outside Diameter | 13.858 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 68.000 MM |
| Center Hole Diameter | 2.677 IN |
| Mounting Bolt Hole Circle Diameter | 4.500 IN |
| Mounting Bolt Hole Circle Diameter | 114.300 MM |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 0.610 IN |
| Stud/Lug Hole Diameter | 15.500 MM |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00805890854289 |
CENTRIC 120.65136 Cross References
| Brand | Part Number |
|---|---|
| ADVICS | K6F152U |
| N/A | 120.65136, BD180535, BD180535E, E125-70-141, 75010GT, U697A, DG131125E, 1407-477752, 42284, YH477752, BRR252, BRRF112, BRRF202, 75010, DG1Z1125B, DG1Z1125C, EU2Z1V125A, 850304, 90054221, E12570141 |
| NEOTEK | 1071116GF |
| Neotek Premium Drums and Rotors | 1071116GF |
| PRONTO | BR90115802 |
| RAYBESTOS | 680982, 680982FZN, 680982P, 680982R, 680982R2 |
| Raybestos Brakes | 680982, 680982FZN, 680982P, 680982R |
| WAGNER | BD180535, BD180535E |
CENTRIC 120.65136 Fits Vehicles
- Ford Police Responder Hybrid (2019-2020)
- Ford Taurus (2013-2019)
- Lincoln MKS (2013-2016)
- Lincoln MKT (2013-2019)
- Ford Police Interceptor Utility (2013-2019)
- Ford Police Interceptor Sedan (2013-2019)
- Ford Explorer (2013-2019)
- Ford Flex (2013-2019)
- Ford Special Service Police Sedan (2014-2018)
