(888) 312-8812 Login SignupCENTRIC 12363006 C-Tek Standard Brake Drum
$67.76
MSRP Pricing shown.
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
CENTRIC 12363006 Part Description
Manufacturer
Product Description
C-Tek Standard Brake Drum
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
- For best operation and ultimate strength
- OE-Matched Fit, Form, and Function
- 100% Mill Balanced
- For vibration free performance
- Meets SAE Standard for Tensile Strength
- For maximum service life and structural integrity
CENTRIC 12363006 Specifications
Product Attributes
| Weight [cntrc] Kgs | 7.159 |
| Weight [cntrc] Lbs | 15.750 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 139.700 |
| Bolt Circle Diameter [cntrc] In | 5.500 |
| Hub Hole / Register [cntrc] Mm | 105.664 |
| Hub Hole / Register [cntrc] In | 4.160 |
| Height [cntrc] Mm | 75.946 |
| Height [cntrc] In | 2.990 |
| Friction Surface Width [cntrc] Mm | 59.690 |
| Friction Surface Width [cntrc] In | 2.350 |
| Product Grade [cntrc] | Standard |
| Maximum Brake Diameter (Discard) | 280.900 MM |
| Maximum Brake Diameter (Discard) | 11.060 IN |
| Bolt Hole Quantity | 5 |
| Outside Diameter | 313.944 MM |
| Outside Diameter | 12.360 IN |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 16.000 MM |
| Mounting Hole Diameter | 0.630 IN |
| Nominal Drum Diameter | 279.400 MM |
| Nominal Drum Diameter | 11.000 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890052500 |
CENTRIC 12363006 Cross References
| Brand | Part Number |
|---|---|
| N/A | BD60139, E128-68-011, E127-68-011, 8753, BD8753, 123.63006, 8753G, J0937604, J0937606, J0938608, J0991995, J0994305, J0999728, 937164, 937604, 937606, 937608, 937849, 991953, 991995, 994303, 994305, 999728, 938606, 938608, 205530, PDR0088, 140088, 6401123, 877, AD8306, AD8306E, D2307, E12768011, 87070, X21414, BD1074, 102307, 2307, 2307R, 2307DGS, 8832006, 78832006, 36542001, 177146 |
| PRONTO | BD8753 |
| RAYBESTOS | 2307R |
| WAGNER | BD60139 |
CENTRIC 12363006 Fits Vehicles
- Jeep J-300 (1965)
- AM General DJ5 (1972-1973)
- Jeep J-210 (1965)
- Jeep J-200 (1965)
- Jeep J-4500 (1970-1973)
- Jeep Jeepster (1967-1971)
- Jeep J-3500 (1965-1970)
- Jeep J-2600 (1965-1973)
- Jeep Wagoneer (1965-1973)
- Jeep J-3600 (1965-1970)
- Jeep J-2500 (1965-1973)
- Jeep J-100 (1965-1973)
- Jeep Gladiator (1965-1969)
- Jeep DJ5 (1972-1973)
- Jeep Commando (1967-1973)
