When a damaged rotor needs replacement, the Meritor Disc Brake Rotor provides the U-shaped disc-brake rotor configuration called for by the matching wheel-end design. The 15.38-inch outside diameter helps identify this rotor, although diameter alone does not establish the mounting geometry or caliper compatibility. The Meritor 23123574009 is a rotor rather than a complete hub-and-rotor assembly, so the surrounding wheel-end components remain part of the existing system. The rotor gives the disc-brake pads their mating friction surface, distinct from the hub, caliper, and hardware that support the rest of the brake assembly.
| Discard Thickness | 1.42 in. |
| Outside Diameter | 15.38 in. |
| Application | Several Medium Duty Vehicle Sizes and Name Plates |
| Bolt Circle Diameter | 11.25 in. |
| Bolt Hole Diameter | 1.00 in. |
| Bolt Hole Quantity | 10 |
| Brand | Meritor Genuine |
| Disc Thickness | 1.54 in. |
| Pallet Quantity | 12 |
| Pilot Diameter | 6.00 in. |
| Rotor Depth | 7.60 in. |
| Type | U-Shape |
| Weight | 61.00 |
| Brand Or Model Compatibility | Meritor Genuine |
| Brand | Part Number |
|---|---|
| 23123574004, RC4414574, TDA23123574009 | |
| CENTRIC | 120.80015 |
