HORTON 79A9643-2 Engine Cooling Fan Clutch

★★★★★ (0)
Horton 79A9643-2 Engine Cooling Fan Clutch Engine Cooling Fan Clutch
HORTON
Tap to view 3 more

MSRP: $1,841.23

$1,362.99

Save $478.24

+$969.71 core deposit
Total price w/ core: $2,332.70

In Stock

Get as soon as Tuesday, Nov 24
30-day Return Policy On eligible items Details
Free Ground shipping on orders over $499 details
Orders placed over the weekend will be processed the next business day.

HORTON 79A9643-2 Part Description

Manufacturer

HORTON

Product Description

Engine Cooling Fan Clutch

Application Summary

MACK, VOLVO

Features & Benefits

  • Built to the same specifications as Horton Genuine models
  • Easy-to-install, exact drop-in replacements
  • Total cost can be less than rebuilding
  • Two-year warranty for line-haul applications
  • Credit for old Horton or competitor cores
  • Low eddy-current speeds reduce noise, increase available horsepower, conserve fuel and minimize radiator abrasion
  • Higher, spring-actuated fan speeds make sure necessary cooling is delivered
  • Faster engine warm-ups in cold weather
  • Premium bearings and friction liners
  • High torque for turning large fans
  • Lower parts count for easy installation and maintenance

Two-speed fan clutch, fan clutch, engine cooling, fan drive, performance, cooling system, horsepower, performance, reman

HORTON 79A9643-2 Specifications

Product Attributes

BACK PULLEY DIAMETER7.56 IN
BELT CONFIGURATION12PK
Belt Groove Location1.48 IN
BOLT CIRCLE3.5 IN
Center of JB To Top Right Mounting Hole2.82 IN
Fan Blade Stud Length1.07 IN
FAN PILOT DIAMETER2.56 IN
Heavy Duty1
HORIZONTAL MOUNTING DISTANCE6.73 IN
Overall Length7.36 IN
Stud Thread Size.375-24 IN
VERTICAL MOUNTING DISTANCE7.21 IN
Fan Bolt Circle3.5
FRONT PULLEY DIAMETER-

Additional Information

Country of Origin (Primary)US
Harmonized Tariff Code (Schedule B)8483604040
Harmonized Tariff Code (HTS)8483604040
OEM's Part Number98A9643-2
Warranty Distance300000
Warranty Distance UOMDH
Warranty Special7500 Hours
Warranty Special UOMTX
Warranty Time36
Warranty Time UOMMO
VMRS Code042003131

HORTON 79A9643-2 Cross References

BrandPart Number
BorgWarner10026462, 21044412
Horton79A5643-2, 98A9643-2, 99A9643-2
KIT MASTERS99643-2
MCI21210839, HOR79A96432, 3912-79A96432, 21508295, 21925081, 22113063, 85139324
Mack21622798, 22113063, 40MH4104M, 85139324, 3912-79A96432
NavistarZBH79A96432
Paccar Parts79A9643-2RMAN
VOLVO22113063
Volvo21210839, 21508295, 21925081, 85139324
