(888) 312-8812 Login SignupDELPHI ES20104 Oxygen Sensor - Front, RH=LH, Heated, 4-Wire, Narrow Band, Threaded Mount, 16.3" Wire Length
$6899
Limited availability at this price!
In Stock
Get it by Thursday, Jul 2
DELPHI ES20104 Part Description
Manufacturer
Product Description
Oxygen Sensor
Features & Benefits
- Delphi planar technology covers older, conical design sensors
- Smart design consolidates SKUs without using long wires
- Patented protective sensor coating helps prevent contamination
- Validated for all fuel types, including ethanol blends like E85
- OE tested to 150,000 miles, plus 2,000 hours severe thermal testing
- Delphi is a global OE manufacturer for oxygen sensor and all oxygen sensors are built to Delphi's OE standards
DELPHI ES20104 Specifications
Product Attributes
| Package Contents | Oxygen Sensor, Instruction Sheet |
| Position(s) | Front, Front Left, Front Right. For the position specific to your vehicle, refer to the Applications. |
| Wiring Harness Length | 16.3 IN |
| Wiring Harness Length | 415.0 MM |
| Sensor Type | Narrow-Band |
| Terminal Type | Bullet |
| Universal Or Specific Fit | Specific |
| Band Type | Narrow |
| Wire Quantity | 4 |
| Grade Type | Standard Replacement |
| Connector Shape | Circle |
| Terminal Quantity | 4 |
| Connector Gender | Female |
| Terminal Gender | Male |
| Thread Diameter | 0.7 IN |
| Wrench Size | 22mm |
| Thread Size | M18 - 1.5 |
| Overall Length | 17.5 IN |
| Overall Length | 445.0 MM |
| Mounting Type | Threaded |
| Thread Diameter | 18.0 MM |
| Wire Gauge Measurement | 20.0 GU |
| Thread Type Standard | Metric |
| Heated | Yes |
Additional Information
| Warranty Distance UOM | DH |
| Warranty Distance | 12000 |
| Harmonized Tariff Code (Schedule B) | 9027100000 |
| Harmonized Tariff Code (HTS) | 9027102000 |
| Warranty Time UOM | MO |
| Warranty Time | 12 |
| Country of Origin (Primary) | CN |
| UPC | 00689604145913 |
| VMRS Code | 045021011 |
| UNSPSC | 41111924 |
DELPHI ES20104 Cross References
| Brand | Part Number |
|---|---|
| ACDelco | 2131317, 2131367, 2131408, 2131459, 2131460 |
| Airtex | 5S3282, 5S3286, 5S3319, 5S3651, 5S4285, 5S7321, 5S7348, 5S8307 |
| BorgWarner | OS123, OS124, OS1479, OS152, OS1949, OS1977, OS1992, OS2244 |
| Bosch | 13541, 13741, 13824, 15628, 15714, 15716, 15717, 15755, 18124 |
| DENSO | 234-4046, 234-4045, 234-4106, 234-4370, 234-4372, 234-4374, 234 4374 |
| DENSO Auto Parts | 2343472, 234-4045, 234-4046, 234-4106, 234-4370, 234-4372, 234-4374 |
| Ford | 3S4A 9F472-B1A, 3S4Z 9F472-BA, 5C5Z 9F472-AA, 5L8Z 9F472-AA, 5L8Z 9F472-BA, 7T4Z 9F472-A, F7VZ 9F472-AA, F8VF 9F472-AA, F8VF 9F472-B2A, F8VF 9F472-BA, F8VF 9F472-BA1, F8VZ 9F472-AA, F8VZ 9F472-BA, XC2F 9F472-A1A, XC2F 9F472-AA, XC2F 9F472-B1A, XC2F 9F472-B2A, XC2F 9F472-BA, XC2F 9F472-BB, XC2Z 9F472-AA, XC2Z 9F472-BA, XC2Z 9F472-BB, XC2Z 9F472A1A, YL84 9F472-BC, YL8Z 9F472-BA |
| Kem | 138-660 |
| Mazda | AJ04-18-861B, CY01-18-861, L3H5-18-861, ZZC3-18-861 |
| Motorcraft | DY-1039, DY-1040, DY-1042, DY-1045, DY-1064, DY-821, DY-823, DY-834, DY-850, DY-863, DY-877 |
| N/A | DY1045, DY1064, DY821, DY823, DY834, DY850, DY863, DY877, 25024301, 2343472, 2344045, 2344046, 2344370, 2344374, AJ0418861B, CY0118861, L3H518861, ZZC318861, 138660, 3S4A9F472B1A, 3S4Z9F472BA, 5C5Z9F472AA, 5L8Z9F472AA, 5L8Z9F472BA, 7T4Z9F472A, F7VZ9F472AA, F8VF9F472AA, F8VF9F472B2A, F8VF9F472BA, F8VF9F472BA1, F8VZ9F472AA, F8VZ9F472BA, XC2F9F472A1A, XC2F9F472AA, XC2F9F472B1A, XC2F9F472B2A, XC2F9F472BA, XC2F9F472BB, XC2Z9F472A1A, XC2Z9F472AA, XC2Z9F472BA, XC2Z9F472BB, YL849F472BC, YL8Z9F472BA, DY1039, DY1040, DY1042, 250-24302, 250-24749, EFTT-18-861 |
| NTK | 22011, 22012, 25584, 22046, 22060 |
| Niehoff | FE80297, FE80325, FE80340, FE80592, FE8823 |
| Oextra | REA1002, REA1011, REA1014 |
| SPECTRA PREMIUM | OS5133, OS5038 |
| Standard Motor Products | SG1198, SG1411, SG179, SG1813, SG1814, SG319, SG448, SG726, SG1809 |
| Tomco | 11139, 11194, 11197, 11206, 11651 |
| VEMO | V25760010, V25760012 |
| Walker Products | 250-24301 |
| Wells | SU2152, SU2177, SU2191, SU2278, SU2352, SU5798, SU6512, SU8811, SU9772 |
DELPHI ES20104 Fits Vehicles
- Ford Taurus X (2008-2009)
- Mercury Sable (2008-2009)
- Ford Taurus (2008-2009)
- Mazda CX-9 (2007-2010)
- Lincoln MKX (2007-2010)
- Ford Edge (2007-2010)
- Lincoln MKZ (2007-2010)
- Lincoln Zephyr (2006)
- Mercury Milan (2006-2009)
- Ford Fusion (2006-2010)
- Mercury Mariner (2005-2009)
- Ford F-250 Super Duty (2005-2010)
- Ford F-350 Super Duty (2005-2010)
- Ford F-450 Super Duty (2005-2008, 2010)
- Ford F-550 Super Duty (2005-2007, 2009-2010)
- Ford E-450 Super Duty (2005-2008)
- Ford E-250 (2005-2008)
- Ford E-350 Super Duty (2005-2008)
- Ford E-150 Club Wagon (2005)
- Ford E-150 (2005-2008)
- Mazda Tribute (2001-2006, 2008)
- Mercury Grand Marquis (1998-1999)
- Mercury Cougar (2000-2001)
- Lincoln Town Car (1998-1999)
- Lincoln Continental (1998)
- Ford Escape (2001-2010)
- Ford Crown Victoria (1998-1999)
