(888) 312-8812 Login SignupDELPHI ES20096 Oxygen Sensor
MSRP: $89.59
$8049
Save $9.10
Limited availability at this price!
In Stock
Get it by Friday, Feb 6
DELPHI ES20096 Part Description
Manufacturer
Product Description
Oxygen Sensor
Features & Benefits
- Delphi planar technology covers older, conical design sensors
- Smart design consolidates SKUs without using long wires
- Patented protective sensor coating helps prevent contamination
- Validated for all fuel types, including ethanol blends like E85
- OE tested to 150,000 miles, plus 2,000 hours severe thermal testing
- Delphi is a global OE manufacturer for oxygen sensor and all oxygen sensors are built to Delphi's OE standards
DELPHI ES20096 Specifications
Product Attributes
| Position(s) | Front, Rear. For the position specific to your vehicle, refer to the Applications. |
| Package Contents | Oxygen Sensor, Instruction Sheet |
| Wiring Harness Length | 12.6 IN |
| Wiring Harness Length | 320.0 MM |
| Sensor Type | Narrow-Band |
| Terminal Type | Blade |
| Universal Or Specific Fit | Specific |
| Band Type | Narrow |
| Wire Quantity | 4 |
| Grade Type | Standard Replacement |
| Connector Shape | Square |
| Terminal Quantity | 4 |
| Connector Gender | Female |
| Terminal Gender | Male |
| Thread Diameter | 0.7 IN |
| Wrench Size | 22mm |
| Thread Size | M18 - 1.5 |
| Overall Length | 13.8 IN |
| Overall Length | 350.0 MM |
| Mounting Type | Threaded |
| Thread Diameter | 18.0 MM |
| Wire Gauge Measurement | 20.0 GU |
| Thread Type Standard | Metric |
| Heated | Yes |
Additional Information
| Warranty Distance UOM | DH |
| Warranty Distance | 12000 |
| Harmonized Tariff Code (Schedule B) | 9027100000 |
| Warranty Time UOM | MO |
| Warranty Time | 12 |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 9027102000 |
| UPC | 00689604145173 |
| VMRS Code | 045021011 |
| UNSPSC | 41111924 |
DELPHI ES20096 Cross References
| Brand | Part Number |
|---|---|
| ACDelco | 2131553, 2131643, 213360, 213968 |
| Airtex | 5S4213, 5S8130 |
| BorgWarner | OS1011, OS1457, OS2134, OS2260 |
| Bosch | 13455, 13683, 15554, 15565, 15898, 15899 |
| DENSO | 234-4646, 234 4646 |
| DENSO Auto Parts | 234-4287, 234-4646 |
| General Motors | 12558143, 12568234, 12574218, 12583190, 19209814 |
| Kem | 138-472, 138-647 |
| N/A | 2344287, 2344646, 138472, 138647, 11647, 12606671, 234-4242, 15697 |
| NTK | 21045, 21055, 21517 |
| Niehoff | FE6335, FE80482, FE80608 |
| Oextra | REA1062, REA1104, REA1778, REA1834 |
| SPECTRA PREMIUM | OS5448 |
| STANDARD IGNITION | SG326 |
| Standard Motor Products | SG1301, SG1427, SG326, SG704, SG1720 |
| Tomco | 11635, 11-647 |
| Walker Products | 25024273 |
| Wells | SU1218, SU1447, SU8712, SU9596 |
DELPHI ES20096 Fits Vehicles
- Chevrolet Captiva Sport (2012-2015)
- GMC Terrain (2010-2014)
- Chevrolet Equinox (2010-2014)
- Saturn Sky (2008-2010)
- Pontiac Solstice (2008-2009)
- Pontiac G6 (2008-2010)
- Chevrolet HHR (2008)
- Saturn Aura (2007-2009)
- Saturn L300 (2004)
- Buick Lucerne (2006-2008)
- Pontiac Bonneville (2004-2005)
- Chevrolet Cobalt (2005-2007)
- Buick LaCrosse (2005-2009)
- Chevrolet Classic (2004-2005)
- Saturn Ion (2003-2007)
- Pontiac Grand Prix (2004-2008)
- Chevrolet Monte Carlo (2004-2005)
- Chevrolet Malibu (2004-2006, 2008-2010)
- Chevrolet Impala (2004-2005)
- Buick Regal (2004)
- Buick LeSabre (2004-2005)
- Buick Park Avenue (2004-2005)
- Saturn Vue (2002-2005, 2008-2010)
- Saturn LW200 (2002-2003)
- Saturn L100 (2002)
- Saturn L200 (2002-2003)
- Pontiac Sunfire (2002-2005)
- Pontiac Grand Am (2002-2005)
- Oldsmobile Alero (2002-2004)
- GMC Safari (1998-1999)
- Chevrolet Cavalier (2002-2005)
- Chevrolet Astro (1998-1999)
