(888) 312-8812 Login SignupDELPHI FG0815 Fuel Pump Module Assembly - 20 GPH Average Flow Rating
MSRP: $553.17
$33599
Save $217.18
Limited availability at this price!
In Stock
Get it by Wednesday, Feb 11
DELPHI FG0815 Part Description
Manufacturer
Product Description
Fuel Pump Module Assembly
Features & Benefits
- Delphi is a global OE manufacturer and all fuel pumps are built to Delphi's OE standards
- Empty float height and float retention matches OE specifications and guarantees correct gas gauge reading
- Lower amperage draws less load on vehicle's electrical system
- Part is validated, tested and matched to the right vehicle application
- Always be sure to check and clean fuel tank to avoid unnecessary returns
- Lower failure rates due to its innovative design and durability
DELPHI FG0815 Specifications
Product Attributes
| Fuel Level Sender Assembly Included | Yes |
| Item Grade | Standard Replacement |
| System Pressure | 55 psi |
| Package Contents | Fuel Pump Module Assembly w/Float Arm, Seal, Instruction Sheet |
| Vapor Pressure Sensor | No |
| Fuel Type | Flex |
| Outlet Outside Diameter | 0.313 IN |
| Voltage | 13 2H |
| Regulator Included | Yes |
| Maximum Pressure | 62 PS |
| Terminal Type | Blade |
| Gasket Or Seal Included | Yes |
| Terminal Quantity | 4 |
| Lock Ring Included | No |
| Terminal Gender | Male |
| Strainer Included | Yes |
| Inlet Type | Strainer |
| Outlet Type | Quick Connect |
| Outlet Quantity | 2 |
| In Tank or External | In Tank |
| Resistance Ohms Empty | 250 82 |
| Resistance Ohms Full | 40 82 |
| Internal Or External Strainer | Internal |
| Pump Type | Electric |
| Average Current Draw | 11 68 |
| Average Flow Rating | 20 GPH |
| Fuel Sending Unit Included | Yes |
| Negative Ground | No |
| Fuel Type | Flex |
| Mounting Hardware Included | No |
| Grade Type | Premium |
| Connector Quantity | 1 |
| Connector Shape | Oval |
| Housing Material | Plastic |
| Installation Warnings | No |
| Connector Gender | Female |
| Fuel Filter Included | Yes |
| Gasket Or Seal Material | Nitrile Rubber |
| Minimum Pressure | 55 PS |
| Wire Harness Included | No |
| Pump Design | Turbine |
| Fuel Tank Pressure Sensor Included | Yes |
| Universal Or Specific Fit | Specific |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8413309000 |
| Harmonized Tariff Code (HTS) | 8413309030 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| Country of Origin (Primary) | TH |
| UPC | 00689604200506 |
| VMRS Code | 044003258 |
| UNSPSC | 25172409 |
DELPHI FG0815 Cross References
| Brand | Part Number |
|---|---|
| ACDelco | M10107, MU1474 |
| AUTOBEST | F2717A |
| Airtex | E3706M |
| AutoZone | CFG0815 |
| Bosch | 66031, 67544 |
| CARTER FUEL PUMPS | P76273M |
| CONTINENTAL AG | FP22041S |
| Carquest | M2480517 |
| Carter | P76273M |
| EVO Driveline | AFS0957S, RE0957S |
| GMB | 530-2278 |
| General Motors | 19133544, 19167711, 19208963, 19208962, 88965801 |
| Magneti Marelli | 1AMFP00075 |
| N/A | USEP3706M, F2717A, D0259M, 4010524 |
| Precision Fuel | A40000 |
| Spectra Premium | SP6603M |
| TYC | 150230-A |
| VDO | FP22041S |
DELPHI FG0815 Fits Vehicles
- Chevrolet Avalanche (2007)
- GMC Yukon XL 1500 (2005-2007)
- Chevrolet Suburban 1500 (2005-2007)
- Chevrolet Avalanche 1500 (2005-2006)
