Centric 123.41002 - C-Tek Standard Brake Drum
$6149
5 day lead time
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
C-Tek Standard Brake Drum
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
Product Attributes
| Weight [cntrc] Kgs | 6.364 |
| Weight [cntrc] Lbs | 14.000 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 139.700 |
| Bolt Circle Diameter [cntrc] In | 5.500 |
| Hub Hole / Register [cntrc] Mm | 106.930 |
| Hub Hole / Register [cntrc] In | 4.210 |
| Height [cntrc] Mm | 66.040 |
| Height [cntrc] In | 2.600 |
| Friction Surface Width [cntrc] Mm | 51.600 |
| Friction Surface Width [cntrc] In | 2.031 |
| Product Grade [cntrc] | Standard |
| Maximum Brake Diameter (Discard) | 254.000 MM |
| Maximum Brake Diameter (Discard) | 10.000 IN |
| Nominal Drum Diameter | 9.988 IN |
| Nominal Drum Diameter | 253.700 MM |
| Mounting Hole Diameter | 0.579 IN |
| Mounting Hole Diameter | 14.700 MM |
| Outer Cooling Fins | No |
| Outside Diameter | 11.693 IN |
| Outside Diameter | 297.000 MM |
| Bolt Hole Quantity | 5 |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 805890914587 |
Part Interchanges
CENTRIC 123.41002 Cross Reference
We have 2 alternatives for the 123.41002 by CENTRIC:
Fits Vehicles
- Daihatsu Rocky (1990-1992)
